Double Switch Curtain Control | 10 A Rated | 2 Round Modules | Glossy White | @Each of 1 | by Legrand
The Double Switch Curtain Control is designed for seamless operation of curtain motors, featuring a robust 10 A rated current and 250 V nominal voltage. Ideal for both residential and commercial applications, this switch is made from halogen-free thermoplastic with a glossy white finish, ensuring durability and aesthetic appeal. Perfect for home automation systems and hospitality environments, it offers reliable performance with IP20 protection and IK04 impact strength.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Double Switch Curtain Control | 10 A Rated | 2 Round Modules | Glossy White | @Each of 1 | by Legrand
Brand: Legrand
SKU: 573235
Alternatively Known As: Curtain motor switch, Double curtain switch, Curtain control switch, 2 module curtain switch
Technical Specifications
- Rated current: 10 A
- Nominal voltage: 250 V
- Number of buttons: 2
- Mounting method: Module frame
- Material: Thermoplastic, halogen free
- Surface finish: Glossy
- Connection type: Screwed terminal
- Degree of protection: IP20
- Impact strength: IK04
- Operating temperature range: -20 to 40 °C
- Storage temperature range: -20 to 40 °C
- Cable section compatibility: 1.5 mm²
- Dimensions (H x L x W): 45mm x 42mm x 45mm
- Weight: 0.1 kg
Key Features
- Double switch for curtain control with 2 modules
- Rated current of 10 A and nominal voltage of 250 V
- Mechanism with fixed positions for direct motor control
- Rocker operation with screwed terminal connection
- Glossy white thermoplastic material, halogen free
- IP20 degree of protection and IK04 impact strength
- Compatible with standard module frame mounting
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and safety.
Applications
- Control of curtain motors in residential and commercial buildings
- Suitable for installation in home automation and building wiring systems
- Ideal for use in hotels and hospitality environments
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen-free materials reduce environmental impact
- Durable thermoplastic construction enhances product lifespan
Warranty Information
Legrand offers a standard warranty covering manufacturing defects; please refer to official documentation for duration and terms.
Available Now
The Legrand Arteor Double Switch Curtain Control 10A 2 Modules White is available for immediate purchase, ideal for residential and commercial curtain motor control applications.
