DPX³ 160 3 Pole + N/2 160A Thermal Magnetic MCCB | 25kA Short-Circuit Capacity | IP30 Rated | @EA of 1 | by Legrand
The DPX³ 160 3 Pole + N/2 160A Thermal Magnetic MCCB is designed for robust electrical protection, featuring a 25kA short-circuit breaking capacity and rated for 220-690V. Ideal for industrial and commercial applications, this MCCB ensures safety and reliability in electrical distribution panels, with a built-in under voltage release and suitable for DIN rail mounting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: DPX³ 160 3 Pole + N/2 160A Thermal Magnetic MCCB | 25kA Short-Circuit Capacity | IP30 Rated | @EA of 1 | by Legrand
Brand: Legrand
SKU: 420740
Alternatively Known As: Legrand DPX3 160A MCCB, Thermal Magnetic Circuit Breaker 160A, 3 Pole MCCB with Neutral, 25kA MCCB
Technical Specifications
- Rated permanent current Iu: 160 A
- Rated voltage: 220-690 V
- Rated short-circuit breaking capacity Icu at 400 V, 50 Hz: 25 kA
- Overload release current setting: 128-160 A
- Adjustment range short-term delayed short-circuit release: 1600 A
- Adjustment range undelayed short-circuit release: 1600 A
- Device construction: Built-in fixed built-in technique
- Integrated earth fault protection: No
- Type of electrical connection of main circuit: Screw connection
- Suitable for DIN rail (top hat rail) mounting: Yes
- Number of auxiliary contacts as normally closed contact: 1
- Number of auxiliary contacts as change-over contact: 1
- With switched-off indicator: Yes
- With integrated under voltage release: Yes
- Number of poles: 3
- Position of connection for main current circuit: Front side
- Type of control element: Wing knob
- Complete device with protection unit: Yes
- Degree of protection (IP): IP30
- Dimensions (H x L x W): 140mm x 75mm x 90mm
- Weight: 3.5 kg
Key Features
- Rated permanent current: 160 A
- Rated voltage: 220-690 V
- Short-circuit breaking capacity: 25 kA at 400 V, 50 Hz
- Overload release current setting: 128-160 A
- Short-term delayed and undelayed short-circuit release adjustment: 1600 A
- Built-in fixed device construction
- Screw connection for main circuit
- Suitable for DIN rail (top hat rail) mounting
- Auxiliary contacts: 1 normally closed, 1 change-over
- Switched-off indicator included
- Integrated under voltage release
- 3 poles with neutral/2
- Front side connection for main current circuit
- Wing knob control element
- Complete device with protection unit
- Degree of protection: IP30
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards and proper integration into the electrical system.
Applications
- Industrial electrical distribution panels
- Commercial and residential electrical protection
- Motor and circuit protection in electrical installations
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances electrical safety reducing risk of fire and equipment damage
- Durable design reduces need for frequent replacements, minimizing waste
Warranty Information
Legrand provides a standard 2-year warranty covering manufacturing defects and performance issues.
Available Now
The Legrand DPX³ 160 3 Pole + N/2 160A Thermal Magnetic MCCB 25kA is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
