Dual Switching Dimmer Kit | 2-Wire Push Button | Timed Dimming Feature | Over Voltage Protection | @EA of 1 | by Cabac
The Dual Switching Dimmer Kit is designed for seamless control of dimmable LED lighting, featuring a 2-wire push button design and a timed dimming function for gradual light adjustment. Ideal for both residential and commercial applications, this kit ensures safety with over current, over voltage, and over temperature protection, making it a reliable choice for any lighting setup.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Dual Switching Dimmer Kit | 2-Wire Push Button | Timed Dimming Feature | Over Voltage Protection | @EA of 1 | by Cabac
Brand: Cabac
SKU: HNS610DSDK
Alternatively Known As: Dual Switching Dimmer, Push Button Dimmer Kit, Multi-Way Dimmer Switch, LED Dimmer Switch Kit
Technical Specifications
- Type: 2-wire push button digital dimmer and remote button
- Compatibility: Suitable for dimmable LED lighting
- Protection: Over current, over voltage, and over temperature protection
- Control: ON/OFF with quick tap, dimming with hold, timed dimming with double tap
- Wall Plate Compatibility: HPM and Clipsal style
- Dimming Time: 30 minutes for timed dimming feature
- Dimensions (H x L x W): 115mm x 40mm x 70mm
- Weight: 0.3 kg
Key Features
- Multi-way dimming and ON/OFF control over standard wiring
- Digital dimmer and ON/OFF switch combined, ideal for dimmable LED lighting
- Push-button style with quick tap ON/OFF and hold to dim
- Double tap activates timed dimming feature for gradual light adjustment
- Rugged design with over current, over voltage, and over temperature protection
- Patented ripple tone rejection technology
Professional Installation Requirements
- Professional installation by a licensed electrician is recommended to ensure compliance with electrical standards and safe operation.
Applications
- Residential lighting control
- Commercial lighting systems
- Multi-way dimming setups
- Compatible with HPM and Clipsal style wall plates
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-saving dimming reduces power consumption
- Extends the lifespan of LED lighting by preventing overcurrent
- Supports efficient lighting control to minimize waste
Warranty Information
3 years warranty against manufacturing defects.
Available Now
The Cabac Dual Switching Dimmer Kit - 610DT is available for immediate purchase, ideal for residential and commercial lighting control applications.
