Dutch Clamp SEG Type 80-110 | Durable Steel | Easy Installation | 8-110mm by Cabac
Dutch clamp seg type 80-110 made from durable steel—ideal for securing pipes and cables. Built for contractors and DIY enthusiasts, with easy installation for reliable support.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Dutch Clamp Seg Type 80-110 | Durable Steel Construction | Easy Installation by Matchmaster
Brand: Cabac
SKU: DC-SEG80-110
Alternatively Known As: SEG Cable Clamp, Dutchclamp SEG Clamp, Medium Voltage Cable Clamp, High Voltage Cable Clamp
Technical Specifications
- Suitable for cable diameters 8-110 mm
- Certified in accordance with NEN-EN-IEC 61914:2009
- Resistant to oils, fats, chemicals, frost, heat, UV, ozone, salt, moisture, acids, and nuclear radiation
- Temperature range: -40°C to 120°C (225°C momentarily)
- Self-extinguishing V-0 (UL94), halogen free
- No magnetism or conductivity
- Stackable with extra centre hole for mounting
- Dimensions (H x L x W): 50mm x 110mm x 110mm
- Weight: 0.5 kg
Key Features
- Resistant to oils, fats, aggressive chemicals, frost, heat, UV, ozone, salt, moisture, acids, and nuclear radiation
- Stackable design with extra centre hole for mounting with 1 bolt
- Self-extinguishing V-0 (UL94) and halogen free
- Temperature range from -40°C to 120°C (225°C momentarily)
- No magnetism or conductivity
- No oxidation, corrosion or sharp angles
- Recyclable
- Lifetime product warranty
Professional Installation Requirements
- Installation should be performed by qualified electrical professionals to ensure proper fastening and compliance with safety standards.
Applications
- Fastening of single or multicore medium and high voltage cables
- Suitable for cables with diameter from 8 to 110 mm
- Electrical installations requiring short-circuit resistant cable clamps
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Recyclable materials reduce environmental impact
- Halogen free and self-extinguishing properties enhance safety and reduce toxic emissions
Warranty Information
Lifetime product warranty provided by the manufacturer.
Available Now
The Cabac Dutch Clamp SEG Type 80-110 is available for immediate purchase, ideal for electrical cable management in medium and high voltage applications.
