EARTHLEAKAGE Relay 30mA 12/24V | DIN Rail Mounting | Enhanced Electrical Safety | by Clipsal
The EARTHLEAKAGE Relay 30mA 12/24V is a reliable residual current monitoring relay designed for enhanced electrical safety. With a sensitivity of 30mA and a wide operating voltage range, it’s perfect for industrial, commercial, and residential applications. Easy to install on DIN rails, this relay ensures continuous protection against earth leakage, making it essential for critical infrastructure.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: EARTHLEAKAGE Relay 30mA 12/24V | DIN Rail Mounting | Enhanced Electrical Safety | by Clipsal
Brand: Clipsal
SKU: SCH56190
Alternatively Known As: Earth Leakage Relay, Residual Current Relay, VigiPacT RH99M, RCD Relay, Earth Fault Relay
Technical Specifications
- Type: Residual current monitoring relay
- Sensitivity: 30mA
- Operating voltage: 12/24VAC 50/60Hz, 12/48VDC
- Current range: 30mA-30A
- Mounting: DIN rail
- SKU: SCH56190
- Dimensions (H x L x W): 90mm x 70mm x 22mm
- Weight: 0.15 kg
Key Features
- Residual current monitoring relay for enhanced electrical safety
- Sensitivity: 30mA for effective earth leakage detection
- Wide operating voltage: 12/24VAC 50/60Hz, 12/48VDC
- DIN rail mounting for easy installation
- Compact design suitable for integration into various panels
- Reliable operation for continuous protection
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with Australian standards and optimal safety.
Applications
- Industrial electrical panels
- Commercial switchboards
- Residential distribution boards
- Critical infrastructure requiring earth leakage protection
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Supports compliance with modern safety standards, promoting safer environments
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal EARTHLEAKAGE Relay 30mA 12/24V RH99M (SCH56190) is available for immediate purchase. Ideal for industrial, commercial, and residential electrical safety applications.
