Easy Teach Sensor KTX-WS41142242ZZZZ | RGB LED Light Source | IP67 Rated | by SICK
The Easy Teach Sensor KTX-WS41142242ZZZZ is designed for industrial automation, featuring a versatile RGB LED light source and an IP67 rated enclosure for dust and water resistance. With a sensing distance of up to 13 mm and a quick response time of 20 µs, this sensor is perfect for quality control and position sensing applications, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10.8 V DC to 28.8 V DC
- Current consumption: less than 100 mA
- Switching frequency: 25 kHz
- Response time: 20 µs
- Jitter: 10 µs
- Output: PNP and NPN switching outputs
- Output current max: 100 mA
- Light source: LED RGB with wavelengths 470 nm, 525 nm, 625 nm
- Light spot size: 0.9 mm x 3.8 mm
- Protection: Reverse polarity, short-circuit, interference pulse suppression
- Operating temperature: -20 °C to +60 °C
- Storage temperature: -25 °C to +75 °C
- Enclosure rating: IP67
- Weight: 94 g
- Dimensions (H x L x W): 53mm x 79mm x 30mm
- Weight: 0.1 kg
Key Features
- Easy Teach device type with 2-point teach-in mode
- Sensing distance up to 13 mm with ±3 mm tolerance
- LED RGB light source with wavelengths 470 nm, 525 nm, 625 nm
- Short device side light emission with vertical light spot direction
- Adjustable delay time and light/dark switching output function
- Protection class III with reverse polarity and short-circuit protection
- IP67 rated enclosure for dust and water resistance
- Shock load resistance according to IEC 60068-2-27 (30 g/11 ms)
- Non-volatile memory with 35 ms retention time
- Male connector M12, 4-pin connection
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and compliance with safety standards.
Applications
- Industrial automation for object detection
- Quality control in manufacturing
- Position sensing in machinery
- Standard sensing applications requiring easy teach-in
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with supply voltage from 10.8 V to 28.8 V DC
- Durable IP67 housing reduces need for frequent replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK KTX-WS41142242ZZZZ Easy Teach Sensor is available for immediate purchase, ideal for industrial automation and sensing applications.
