Easypact CVS100F TM100D Circuit Breaker | 100A Rated Current | 25kA Breaking Capacity | 3 Poles | @Pack of 1 | by Clipsal
The Easypact CVS100F TM100D Circuit Breaker is a reliable thermal-magnetic circuit breaker designed for commercial and industrial electrical distribution. With a rated current of 100A and a breaking capacity of 25kA at 415V AC, it provides essential protection against overloads and short circuits. Its compact design ensures easy installation and maintenance, making it ideal for panel boards and switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Easypact CVS100F TM100D Circuit Breaker | 100A Rated Current | 25kA Breaking Capacity | 3 Poles | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLV510337
Alternatively Known As: Easypact CVS100F, TM100D Circuit Breaker, SCHLV510337, Clipsal MCCB, 100A MCCB, Easypact MCCB
Technical Specifications
- Rated current: 100A
- Breaking capacity: 25kA at 415V AC
- Number of poles: 3
- Trip unit: TM-D (Thermal Magnetic)
- Rated operational voltage: 690V AC
- Mounting: Fixed
- Standards: IEC 60947-2 compliant
- Dimensions (H x L x W): 130mm x 60mm x 76mm
- Weight: 1.2 kg
Key Features
- Thermal-magnetic circuit breaker for reliable protection
- Adjustable thermal protection for overloads
- Magnetic protection for short-circuit events
- Compact and robust design
- Easy installation and maintenance
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with Australian standards and local regulations.
Applications
- Commercial and industrial electrical distribution
- Panel boards and switchboards
- Protection of electrical circuits against overloads and short circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and equipment damage
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal Easypact CVS100F TM100D Circuit Breaker (SCHLV510337) is available for immediate purchase. Ideal for commercial and industrial electrical distribution applications.
