Eaton 9PX 3000VA UPS | 2U Rack/Tower | Hot Swappable Battery & Online Topology | 240V by Eaton
Eaton 9PX 3000VA UPS with 2U rack/tower form factor and hot swappable sealed lead-acid battery—ideal for data centers and telecommunications. Built for critical power protection, featuring online double-conversion topology and a noise level under 40 dB.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Eaton 9PX 3000VA UPS | 2U Rack/Tower | Hot Swappable Battery & Online Topology | 240V by Eaton
Brand: Eaton
SKU: 9103-83800EN1
Alternatively Known As: Eaton 9PX 3000VA UPS, Eaton 9PX 3000W UPS, Eaton 9PX Rack UPS, Eaton 9PX Tower UPS, Eaton 9PX 2U UPS
Technical Specifications
- Power Rating: 3000 VA / 3000 W
- Input Voltage: 240 V nominal, range 176-276 Vac without derating
- Output Voltage: 240 V nominal
- Output Frequency: 50/60 Hz
- Output Waveform: Sine wave
- Output Power Factor: 1.0
- Input Frequency Range: 40-70 Hz
- Battery Type: Sealed, lead-acid, hot swappable
- Receptacles: IEC C13 x 8, IEC C19 x 2
- Noise Level: <40 dB at 1 meter
- Operating Temperature: 0° to 40°C
- Relative Humidity: 0-96% non-condensing
- Form Factor: 2U Rack/Tower
- Internal Bypass: Yes
- Auto Shutdown Function: Yes
- Expansion Slots: One slot for optional communication card
- Dimensions (H x L x W): 86.5mm x 440mm x 605mm
- Weight: 27.57 kg
Key Features
- Online/Double-conversion topology for consistent power quality
- Multilingual graphical LCD display for easy monitoring
- Hot swappable sealed lead-acid battery
- Supports extended battery capability
- Output power factor of 1.0 for maximum usable power
- Input voltage range 176-276 Vac without derating
- Internal bypass for uninterrupted power supply during maintenance
- Noise level less than 40 dB at 1 meter
- Rack/tower form factor suitable for 2U 19-inch racks
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and optimal UPS performance.
Applications
- Data centers and server rooms
- Telecommunications equipment
- Medical and laboratory equipment
- Industrial and commercial power protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- High efficiency reduces energy consumption and operational costs
- Extended battery life reduces battery waste
- Supports power management software to optimize energy use
Warranty Information
Standard Eaton warranty applies; refer to Eaton for specific warranty terms and conditions.
Available Now
The Eaton 9PX 3000VA/3000W 2U Rack/Tower UPS is available now for immediate purchase. Ideal for critical power protection in data centers, telecommunications, and industrial applications.
