Eaton 9PX UPS Power Module | 11kVA Power Rating | Online Double-Conversion | Energy Star Qualified by Eaton
Eaton 9PX UPS Power Module with 11kVA power rating and online double-conversion topology—ideal for data centers and critical power applications. Built for reliable power backup, with energy-efficient design and multiple communication options.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Eaton 9PX UPS Power Module | 11kVA Power Rating | Online Double-Conversion | Energy Star Qualified by Eaton
Brand: Eaton
SKU: 9104-32411
Alternatively Known As: Eaton 9PX UPS Power Module, Eaton 9PX 11kVA UPS, Eaton 9PX 10kW UPS Module, Eaton 9PX Rack UPS
Technical Specifications
- Power Rating: 11 kVA / 10 kW
- Input Voltage: 230V nominal (range 176-276 V, 100-276 V with derating)
- Output Voltage: 230V nominal (adjustable 200/208/220/230/240/250 V ±1%)
- Output Power Factor: 0.9
- Topology: Online double-conversion
- Form Factor: Rack/tower, 3U height
- Input Frequency Range: 40-70 Hz
- Output Frequency: 50/60 Hz
- Noise Level: <50 dB at 1 meter
- Communication Interfaces: USB (HID), Serial (RS232), Mini terminal blocks, Dry contacts, DB15 for parallel operation
- Battery Management: ABM & temperature compensated charging, automatic battery test, deep discharge protection
- Extended Battery Capability: Yes, with automatic recognition
- Operating Temperature Range: 0° to 40°C
- Relative Humidity: 0-95% non-condensing
- Efficiency at Max Load: 95%
- Internal Bypass: Yes
- Auto Shutdown Function: Yes
- Dimensions (H x L x W): 440mm x 700mm x 130mm
- Weight: 21 kg
Key Features
- Online double-conversion topology for consistent power quality
- 0.9 output power factor delivering more real power
- Multilingual graphical LCD display for easy monitoring
- Internal bypass for service continuity during UPS faults
- Energy Star qualified for high efficiency and reduced energy costs
- Supports extended battery capability with automatic recognition
- Multiple communication options including USB, serial, and dry contacts
Professional Installation Requirements
- Professional installation by a qualified electrician is required to ensure compliance with electrical standards and safe operation.
Applications
- Data centers and server rooms requiring reliable power backup
- Telecommunications equipment protection
- Industrial and commercial critical power applications
- Rack or tower installation environments
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Energy Star qualification ensures reduced energy consumption and lower carbon footprint
- High efficiency (95% at max load) reduces cooling requirements and operational costs
Warranty Information
Standard Eaton warranty applies; typically 2 years covering manufacturing defects and performance issues.
Available Now
The Eaton 9PX 11kVA 1:1 UPS Power Module is available for immediate purchase, ideal for critical power protection in data centers, telecommunications, and industrial applications.
