Eaton 9SX Tower EBM 36V | Extended Battery Module | 6 x 12V Sealed Lead-Acid | Free Standing by Eaton
Eaton 9SX Tower EBM 36V is an extended battery module designed for Eaton 9SX UPS systems, featuring 6 x 12V sealed lead-acid batteries and a free-standing tower form factor. Ideal for data centers and industrial applications, it ensures reliable backup power and compliance with safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Eaton 9SX Tower EBM 36V | Extended Battery Module | 6 x 12V Sealed Lead-Acid | Free Standing by Eaton
Brand: Eaton
SKU: 9000-00352
Alternatively Known As: Eaton 9SX Extended Battery Module, Eaton 9SX EBM 36V, UPS Battery Extension Module
Technical Specifications
- Battery rating: 12 V / 9 Ah
- Battery type: Sealed, lead-acid
- Battery quantity: 6
- Form factor: Tower
- Construction type: Free standing model
- Includes: Extended battery module, EBM power cable, EBM detection cable, Quickstart guide
- Dimensions (H x L x W): 252mm x 387mm x 160mm
- Weight: 19 kg
Key Features
- Extended battery module (EBM) for Eaton 9SX UPS
- 36V sealed lead-acid batteries
- Includes EBM power cable and detection cable
- Free standing tower form factor
- Compatible with 9SX1000I, 9SX1000IM, 9SX1000B, 9SX1000IB models
Professional Installation Requirements
- Professional installation by qualified technicians is recommended to ensure proper connection and safety compliance.
Applications
- Backup power supply for Eaton 9SX UPS systems
- Data centers and server rooms
- Telecommunications equipment
- Industrial and commercial power protection
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Sealed lead-acid batteries are recyclable and designed for safe disposal
- Extends UPS runtime reducing the need for additional power sources
Warranty Information
Standard Eaton warranty applies; typically 2 years limited warranty on battery modules.
Available Now
The Eaton 9SX Tower EBM 36V (1kVA) is available now for immediate purchase. Ideal for extending backup power in critical UPS applications.
