Eaton Soft Starter 24A | 200-480V AC | SmartWire-DT Interface | NEMA 1 IP20 by Eaton
Eaton Soft Starter with 24A rated current and 200-480V AC mains voltage—ideal for soft starting three-phase motors. Built for industrial applications, it features a SmartWire-DT communication interface and efficient operation with internal bypass contacts.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Eaton Soft Starter 24A | 200-480V AC | SmartWire-DT Interface | NEMA 1 IP20 by Eaton
Brand: Eaton
SKU: Y7-134949
Alternatively Known As: Eaton DS7 Softstarter, DS7 Motor Soft Starter, Eaton Soft Start Motor Controller
Technical Specifications
- Rated operational current (Ie) at AC-53: 24 A
- Mains voltage range: 200 - 480 V AC
- Control supply voltage: 24 V DC
- Number of outputs: 2 Relay Outputs (TOR, Ready) at 250 V AC
- Degree of protection: NEMA 1 IP20
- Fault memory capacity: 8 faults
- Ramp/run-up time: 1 - 30 seconds
- Start voltage range: Min 30% to Max 100%
- Terminal capacity (flexible with ferrule): 0.75 - 10 mm²
- Shock resistance: 8 g, 11 ms
- Vibration resistance: 2M2 to EN 60721-3-2
- Ambient operating temperature: -5 °C to 40 °C
- Communication interface: SmartWire-DT built-in
- Overvoltage category: II
- Pollution degree: 2
- Rated operational power at 400 V, 50 Hz: 11 kW
- Rated operational power at 220/230 V, 50 Hz: 5.5 kW
- Dimensions (H x L x W): 150mm x 126mm x 45mm
- Weight: 0.4 kg
Key Features
- Soft start function with current limitation and suppression of DC components
- Internal bypass contacts for efficient operation
- SmartWire-DT built-in communication interface
- Fault memory with 8 fault records
- Suitable for vertical mounting
- Protection against direct contact (Finger and back-of-hand proof)
- Shock resistance of 8 g, 11 ms mechanical
- Vibration resistance compliant with EN 60721-3-2
- Ambient operating temperature range from -5 °C to 40 °C
- Overvoltage category II and pollution degree 2
Professional Installation Requirements
- Professional installation by a qualified electrician or technician is required to ensure compliance with electrical safety standards and proper integration with motor control systems.
Applications
- Soft starting of three-phase asynchronous motors
- Industrial motor control and protection
- Branch circuits for three-phase loads
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Reduces mechanical stress on motors and electrical networks during startup, extending motor life and reducing maintenance waste
- Energy-efficient soft starting reduces peak power consumption
Warranty Information
Standard Eaton warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton DS7 Soft Starter 24A is available for immediate purchase, ideal for industrial motor control applications requiring efficient soft starting and communication capabilities.
