Eaton Surge Protection Filter | 40 kA Fault Current | IP24 Rated | Portable by Eaton
Eaton Surge Protection Filter with 40 kA fault current capacity and IP24 rating—ideal for point of use protection in single-phase electrical systems. Built for residential and commercial use, it ensures safety and longevity of connected devices.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Eaton Surge Protection Filter | 40 kA Fault Current | IP24 Rated | Portable by Eaton
Brand: Eaton
SKU: PSF16I
Alternatively Known As: Eaton Surge Protection Filter, Eaton PSF16I Surge Protector, IEC 16A Surge Filter
Technical Specifications
- Product Name: Eaton Surge protection
- Catalog Number: PSF16I
- Fault current: 40 kA
- Connection: Single-phase
- Phase: Single-phase
- Class: Class 3 Cat A
- Degree of Protection: IP24
- Mounting Method: Portable
- Configuration: Diverter-filter-diverter
- Maximum continuous operating voltage: 320 V
- Maximum discharge current 8x20us (Imax): 40 kA
- Nominal discharge current 8x20us (In): 3 kA
- Application: Point of use protection
- Dimensions (H x L x W): 55mm x 205mm x 90mm
- Weight: 1 kg
Key Features
- Class 3 Cat A surge protection
- Portable mounting method
- Diverter-filter-diverter configuration
- IP24 degree of protection
- Fault current capacity of 40 kA
- Maximum continuous operating voltage of 320V
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure proper connection and compliance with electrical standards.
Applications
- Point of use protection for electrical devices
- Single-phase electrical systems requiring surge protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Protects electrical equipment from surge damage, reducing electronic waste
- Enhances longevity of connected devices, minimizing replacement frequency
Warranty Information
Standard Eaton warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton 16A Series Filter with IEC 16A input/output sockets is available now for immediate purchase. Ideal for protecting single-phase electrical devices at the point of use.
