'Edgy Double Powerpoint 10A 250V AC Type A+C 2.1A USB White Kasta'
'Kasta Edgy double powerpoint features 10A 250V AC rating, Type A+C 2.1A dual USB charging and horizontal white design. Ideal for modern home interiors.'
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Kasta Edgy Unison Double Horizontal Powerpoint, Double GPO with USB-C, Double Wall Socket with USB Charging
Technical Specifications
- Electrical Rating: 10A, 250V a.c.
- Power Supply: 220–240V a.c., 50Hz
- USB Charging: Type A+C, 2.1A
- Configuration: Double horizontal powerpoint
- IP Rating: IP20
- Operating Temperature: -20°C to 40°C
- Plate Depth: 7.8mm
- Mounting Points: 84mm, 100mm and corner fixing points
- Terminal Size: 16mm², accommodates up to 4 x 2.5mm² cables
- Terminal Screws: Combination flat/Phillips head
- Housing Material: Polycarbonate
- Finish: Gloss white
- Product Code: EG2PPHU2AC-WH
- SAP Code: 7500146
- Estimated Product Weight: Approximately 0.18kg; manufacturer weight not published
- Dimensions (H x L x W): 80mm x 121mm x 44mm
- Weight: 0.18 kg
Key Features
- Two 10A Australian socket outlets in a horizontal layout
- Integrated USB Type A and USB Type C charging ports
- 2.1A USB charging output
- Slim 7.8mm contemporary Edgy plate design
- Gloss white finish with UV-stabilised construction
- Suitable for standard first-fix mounting accessories
- Flush mounting centres for installation flexibility
- IP20 rated for indoor applications
Professional Installation Requirements
- Installation and connection to mains wiring must be performed by a licensed electrical contractor in accordance with applicable Australian electrical installation requirements.
Applications
- Residential power outlets
- Apartment and multi-residential developments
- Hotels and hospitality fit-outs
- Bedrooms, living areas and home offices
- Commercial interior refurbishments
- Charging mobile phones, tablets and other USB-powered devices
Standards & Compliance
- CoS SAA 183650
- AS/NZS 60669.2.1
- AS/NZS 60669.1
- AS/NZS CISPR 15
- AS/NZS 4268
Environmental Benefits
- Integrated USB charging can reduce reliance on separate plug-in charging adapters
- Durable polycarbonate construction may extend service life and reduce replacement waste
- USB charging supports efficient low-voltage charging for compatible personal electronics
Warranty Information
KASTA Edgy Unison product documentation states a 5-year warranty, subject to the manufacturer's warranty terms and conditions.
Available Now
Available through KASTA authorised Australian electrical wholesalers, distributors and retail stockists.
