'Edgy Double Powerpoint 10A Type A+C 2.1A USB Matte Black Kasta'
'Kasta Edgy double powerpoint features 10A 250V AC rating, Type A+C 2.1A dual USB charging and horizontal matte black design. Ideal for modern home interiors.'
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: KASTA Edgy Double GPO with USB Charger, KASTA Unison Double Horizontal Powerpoint, Double Power Outlet with USB A+C
Technical Specifications
- Product Code: EG2PPHU2AC-MBK
- SAP Code: 7500147
- Outlet Configuration: Double powerpoint, horizontal
- AC Rating: 10A, 250V a.c.
- Power Supply: 220–240V a.c., 50Hz
- USB Ports: 1 x Type A and 1 x Type C
- USB Output: 2.1A at 5V d.c.
- Ingress Protection: IP20
- Operating Temperature: -20°C to 40°C
- Plate Depth: 7.8mm
- Terminal Size: 16mm², accommodating up to 4 x 2.5mm² cables
- Housing Material: Polycarbonate
- Finish: Matte black
- Mounting Points: 84mm, 100mm and corner mounting points
- Dimensions (H x L x W): 121mm x 80mm x 44mm
- Weight: 0.3 kg
Key Features
- Two Australian-style 10A power outlets
- Integrated Type A and Type C USB charging ports
- Combined USB output rated at 2.1A at 5V d.c.
- Slim horizontal Edgy series design
- Matte black finish for contemporary interiors
- Polycarbonate housing with colour-coded terminals
- Suitable for flush mounting into compatible wall boxes
- IP20 rating for indoor use
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with applicable Australian wiring rules, manufacturer instructions and local regulations. Isolate mains power before installation.
Applications
- Residential power and USB charging points
- Bedrooms, living rooms and home offices
- Hospitality and accommodation fit-outs
- Commercial interiors and office spaces
- Modern renovation and new-build electrical installations
Standards & Compliance
- Certificate of Suitability (CoS): SAA 183650
- AS/NZS 60669.2.1
- AS/NZS 60669.1
- AS/NZS CISPR 15
- AS/NZS 4268
Environmental Benefits
- Integrated USB charging can reduce reliance on separate plug-in charging adapters and power points
- Durable polycarbonate construction may support extended product service life and reduce replacement waste
- Compact combined outlet and charging design can reduce the number of separate electrical accessories required
Warranty Information
KASTA provides a three-year limited warranty from the date of purchase through an authorised KASTA dealer, distributor or electrical wholesaler, subject to the manufacturer’s warranty terms and exclusions.
Available Now
Available through KASTA and authorised Australian electrical wholesalers and distributors.
