Ektor Lynk Razor Recessed Emergency Edgelite Exit | Wireless Monitoring | 90 Min Emergency Duration | 16m Viewing Distance | by Ektor
The Ektor Lynk Razor Recessed Emergency Edgelite Exit is designed for reliable emergency exit signage in commercial and public spaces. Featuring wireless IEC62386-104 monitoring, a 90-minute emergency duration, and a 16-meter viewing distance, this exit sign ensures safety and compliance. Built with a durable polycarbonate body and PMMA diffuser, it’s perfect for offices, healthcare facilities, and retail venues.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Emergency Exit Sign, Recessed Emergency Exit Light, Wireless Emergency Exit Sign, LED Exit Sign, Emergency Edgelite Exit
Technical Specifications
- IP Rating: IP20
- Body Material: Polycarbonate
- Diffuser Material: PMMA
- Installation Type: Recessed
- Working Temperature Range: 0 to 40 °C
- Input Frequency: 50 Hz
- Maximum Wattage: 3.7 W
- Input Voltage: 230Vac (-6%/+10%)
- Standby Power: 1.7 W
- Driver Type: Wireless IEC62386-104 with DT1
- Driver Included: Yes
- Integrated Driver: Yes
- Dimmable: No
- Flex & Plug Length: 1200 mm
- Wiring Type: Re-wireable Flex & Plug (2 pin)
- Emergency Mode: Maintained
- Emergency Duration: 90 mins
- Viewing Distance: 16 m
- Decal Size: 200 x 100 mm
- Emergency Output Power: 1000 mW
- Emergency Light Source Life: 18 years
- Product Design Life: 12 years
- Standards Compliance: AS/NZS 60598.1, AS 60598.2.22, AS/NZS 61347.1, AS/NZS 61347.2.13, AS CISPR 15, AS/NZS 2293.3
- Dimensions (H x L x W): 150mm x 50mm x 300mm
- Weight: 1.5 kg
Key Features
- Recessed installation with polycarbonate body and PMMA diffuser
- Maintained emergency mode with wireless IEC62386-104 (DT1) monitoring
- Emergency duration of 90 minutes with 16 meter viewing distance
- Integrated driver with 3.7W maximum wattage and 230Vac input voltage
- Supports wireless test and monitoring compliant with IEC62386-202
- Product design life of 12 years with 8 years commercial warranty
- IP20 rated for indoor use
- DALI Monitored emergency control option
Professional Installation Requirements
- Professional installation by a qualified electrician is required to ensure compliance with Australian standards and optimal emergency functionality.
Applications
- Commercial buildings emergency exit signage
- Office buildings and public spaces
- Healthcare and educational facilities
- Retail and hospitality venues
Standards & Compliance
- AS/NZS 2293 – Emergency Escape Lighting and Exit Signs
Environmental Benefits
- Long product design life reduces waste and replacement frequency
- Low standby power consumption minimizes energy use
- LED technology offers energy-efficient emergency lighting
Warranty Information
8 years return to base (RTB) commercial use warranty.
Available Now
The Ektor Lynk Razor Recessed Emergency Edgelite Exit 16M PRO with wireless is available for immediate purchase, ideal for commercial and public building emergency exit signage.
