Trade Discount 17%
Ektor Razor Recessed EM Edgelite Exit | IP20 Rated | Maintained Emergency Mode | 16m Viewing Distance | by Ektor
The Ektor Razor Recessed EM Edgelite Exit Sign is designed for reliable emergency exit signage in commercial and industrial settings. With an IP20 rating and a maintained emergency mode providing 90 minutes of illumination, this exit sign ensures safety compliance. Its sleek black design and integrated wireless control make it perfect for modern facilities, while the polycarbonate body and PMMA diffuser guarantee durability and efficiency.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Emergency Exit Sign, LED Exit Light, Recessed Exit Sign, Maintained Emergency Exit Light
Technical Specifications
- IP Rating: IP20
- Input Voltage: 230Vac (-6%/+10%)
- Maximum Wattage: 3.7 W
- Standby Power: 1.7 W
- Input Frequency: 50 Hz
- Emergency Duration: 90 minutes
- Emergency Output Power: 1000 mW
- Viewing Distance: 16 meters
- Decal Size: 200 x 100 mm
- Driver Type: Wireless IEC62386-104 with DT1
- Installation Type: Recessed
- Operating Temperature Range: 0 to 40 °C
- Material: Polycarbonate body, PMMA diffuser
- Dimmable: No
- Flex & Plug Length: 1200 mm
- Wiring Type: Re-wireable Flex & Plug (2 pin)
- Dimensions (H x L x W): 150mm x 50mm x 300mm
- Weight: 1.2 kg
Key Features
- Recessed installation with polycarbonate body and PMMA diffuser
- Maintained emergency mode with 90 minutes duration
- Wireless IEC62386-104 (DT1) emergency control with monitoring
- Low standby power consumption of 1.7 W
- Viewing distance of 16 meters
- Integrated driver included, non-dimmable
- Supports wireless test and monitoring compliant with IEC62386-202
- Product design life of 12 years with 8 years commercial warranty
Professional Installation Requirements
- Professional installation by a qualified electrician is required to ensure compliance with Australian standards and proper emergency lighting functionality.
Applications
- Commercial buildings emergency exit signage
- Public facilities requiring maintained emergency lighting
- Industrial and office environments for safety compliance
Standards & Compliance
- AS/NZS 2293 – Emergency Escape Lighting and Exit Signs
- AS/NZS 60598 – General Requirements for Luminaires
- AS/NZS 61347 – Lamp Control Gear
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance Characteristics
Environmental Benefits
- Energy-efficient LED technology reduces power consumption during standby and emergency operation
- Long product design life minimizes waste and replacement frequency
Warranty Information
8 years return to base warranty for commercial use.
Available Now
The Ektor Razor Recessed EM Edgelite Exit Sign - 16M - Black - PRO is available for immediate purchase, ideal for commercial and industrial emergency lighting applications.
