Electra 1.5mm 2 Core & Earth Flat Cable | 100 Metre Drum | PVC Insulation & Sheath | @M of 100 | by Electra Cables
Electra 1.5mm 2 Core & Earth Flat Cable is designed for reliable electrical performance in residential and commercial wiring. With a durable PVC insulation and sheath, this flat cable is easy to install in confined spaces, making it ideal for lighting circuits and power outlets. Supplied in a convenient 100 metre drum, it ensures compliance with AS/NZS standards for safety and reliability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Electra 1.5mm 2 Core & Earth Flat Cable | 100 Metre Drum | PVC Insulation & Sheath | @M of 100 | by Electra Cables
Brand: Electra Cables
SKU: XSRF3015V-100WH
Alternatively Known As: 1.5mm twin and earth cable, 1.5mm flat TPS cable, 2 core and earth electrical cable, Electra TPS cable, XSRF3015V-100WH
Technical Specifications
- Conductor size: 1.5mm²
- Number of cores: 2 + earth
- Conductor material: Plain annealed copper
- Insulation: PVC V-90
- Sheath: PVC 3V-90
- Voltage rating: 450/750V
- Maximum current rating: 18A
- Operating temperature: -15°C to +90°C
- Drum length: 100 metres
- Colour: White sheath
- Dimensions (H x L x W): 4.5mm x 100000mm x 8mm
- Weight: 8.5 kg
Key Features
- 1.5mm² copper conductors for reliable electrical performance
- 2 core plus earth configuration for safety and compliance
- Flat cable design for easy installation in confined spaces
- Supplied in a 100 metre drum for convenience
- PVC insulation and sheath for durability and protection
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Residential and commercial electrical wiring
- Lighting circuits
- Power outlets
- General indoor fixed wiring
Standards & Compliance
- Complies with AS/NZS 5000.2 for electric cables
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Long-lasting and durable, reducing the need for frequent replacements
- PVC insulation is lead-free and compliant with RoHS standards
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Electra 1.5mm 2 Core & Earth Flat Cable 100 Metre Drum is available for immediate purchase. Ideal for residential and commercial fixed wiring applications.
