Electromechanical Relay 10A 1CO | LED Indicator | Lockable Test Button by Clipsal
Electromechanical relay with 10A rated current and 1 changeover contact—ideal for industrial automation and control panels. Built for durability, with LED indicator and lockable test button for safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Harmony Electromechanical Relays, Interface plug in relay, 10A, 1CO, with LED, lockable test button, 12V DC
Brand: Clipsal
SKU: RXG12JD
Alternatively Known As: Electromechanical Relay, Plug-in Relay, Interface Relay
Technical Specifications
- Rated current: 10A
- Control circuit voltage: 12V DC
- Contact resistance: 100 mOhm
- Insulation resistance: 1000 MOhm at 500V DC
- Electrical insulation class: Class F
- Maximum switching voltage: 250V AC / 30V DC
- Operating time: 20 ms
- Reset time: 20 ms
- Dielectric strength: 1000V AC between contacts
- Vibration resistance: 3 gn in operation
- Dimensions (H x L x W): 36mm x 127mm x 33mm
- Weight: 0.02 kg
Key Features
- 10A rated current with 1 changeover contact (1CO).
- LED indicator for operational status.
- Lockable test button for safety and convenience.
- High mechanical durability with 10 million cycles.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial: Automation systems, control panels
- Commercial: Building management systems, machinery control
Standards & Compliance
- Complies with UL 508, CSA C22.2 No 14, IEC 61810-1.
Environmental Benefits
- Green Premium product with environmentally friendly packaging.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Clipsal Harmony Electromechanical Relay is available now for immediate purchase. Ideal for industrial automation and control applications.
