Electronic Circuit Breaker 1600A | LSI Overload Protection | High Short-Circuit Capacity | IP20 by Eaton
The Eaton NZMH4-VX1600 is a 1600A electronic circuit breaker featuring LSI overload protection and high short-circuit breaking capacity up to 63 kA. Ideal for industrial and commercial power distribution, it ensures reliable protection with a USB interface for configuration and test functions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Electronic Circuit Breaker 1600A | LSI Overload Protection | High Short-Circuit Capacity | IP20 by Eaton
Brand: Eaton
SKU: Y7-191456
Alternatively Known As: NZM4 PXR20 Circuit Breaker, Eaton 1600A Circuit Breaker, Molded Case Circuit Breaker 1600A, Electronic Circuit Breaker 3 Pole
Technical Specifications
- Dimensions (H x L x W): 170mm x 375mm x 210mm
- Weight: 19 kg
Key Features
- Electronic release system with LSI overload protection
- Delayed and non-delayed short-circuit protective device
- R.m.s. value measurement and thermal memory
- USB interface for configuration and test functions
- Optional communication-capable with interface module and internal Modbus RTU or CAM
- High short-circuit breaking capacity up to 63 kA at 230 V
- Rated operational current of 1600 A
- Screw terminal electrical connection
- IP20 degree of protection in operating controls area
- Mechanical lifespan of 10,000 operations and electrical lifespan up to 20,000 operations at 690 V AC-1
Professional Installation Requirements
- Installation must be performed by a qualified electrician familiar with high-current circuit breakers and compliance with local electrical standards.
Applications
- Industrial electrical panels
- Commercial power distribution systems
- Motor drive protection
- Generator and cable protection in unearthed supply systems at 525 V
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant, ensuring reduced hazardous substances
- Durable design reduces need for frequent replacements, minimizing waste
Warranty Information
Standard Eaton warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton NZMH4-VX1600 circuit breaker is available for immediate purchase, ideal for industrial and commercial electrical distribution and protection applications.
