Electronic Overload Motor Relay 5-25A | Adjustable Current Range | IP20 Protection | by Clipsal
The Electronic Overload Motor Relay 5-25A is designed for reliable motor protection, featuring an adjustable current range from 5 to 25A and a wide control voltage of 200–240V AC. Ideal for industrial applications such as pumps, compressors, and HVAC systems, this relay offers selectable manual or automatic reset, ensuring optimal performance and safety in automation panels.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Electronic Overload Motor Relay 5-25A | Adjustable Current Range | IP20 Protection | by Clipsal
Brand: Clipsal
SKU: SCHLR97D25M7
Alternatively Known As: motor overload relay, electronic motor protection relay, TeSys overload relay, LR97D25M7, Schneider overload relay
Technical Specifications
- Current adjustment range: 5–25A
- Control voltage: 200–240V AC
- Trip class: 10A
- Phase failure sensitivity
- Selectable manual/automatic reset
- Mounting: DIN rail or panel
- Operating temperature: -20°C to +60°C
- IP20 protection rating
- Dimensions (H x L x W): 70mm x 80mm x 45mm
- Weight: 0.25 kg
Key Features
- Electronic overload relay for motor protection
- Adjustable current range: 5 to 25A
- Wide control voltage: 200–240V AC
- Reliable protection against phase failure and unbalanced currents
- Manual or automatic reset selectable
- Compact design for easy panel integration
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local wiring rules and standards.
Applications
- Industrial motor protection
- Pumps and compressors
- HVAC systems
- Conveyor systems
- Manufacturing automation panels
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Prevents motor damage, reducing equipment waste
- Enhances energy efficiency by protecting motors from overload
- Supports longer equipment lifespan, minimizing resource consumption
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal Electronic Overload Motor Relay 5-25A (SCHLR97D25M7) is available for immediate purchase. Ideal for industrial motor protection and automation panels.
