Emergency Stop Button ES21-SA13H1 | Illuminable Pushbutton | IP54 Rated | by SICK
The Emergency Stop Button ES21-SA13H1 is designed for industrial safety applications, featuring an illuminable pushbutton and IP54 enclosure rating for dust and splash protection. With positive action N/C contacts and rotary release, it ensures reliable emergency stop functionality in manufacturing environments, making it ideal for safety systems and machinery control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Positive action N/C contacts: 2
- N/O contacts: 1
- Actuation directions: 1
- Emergency stop pushbutton: Illuminable
- Obstruction protection: Yes
- Release type: Rotary release
- Labeling: "EMERGENCY STOP"
- B10d parameter: 2.5 x 10^5 switching cycles
- Safe series connection: None, only individual wiring with diagnostics
- Connection type: Cable gland, 2 x M20
- Conductor cross section: ≤ 2.5 mm²
- Contact: Screw connection
- Protection class: II (EN 50178)
- Switching principle: Slow action switching element
- Usage category: AC-15/DC-13 (EN 60947-5-1)
- Rated operating current: 3 A (250 V AC), 2 A (24 V DC)
- Rated insulation voltage Ui: 600 V
- Switching voltage: ≥ 5 V DC
- Switching current: ≥ 1 mA
- Supply voltage Vs: 24 V DC (12 V DC ... 30 V DC)
- Power consumption: 8 mA ... 44 mA
- Life time: 70,000 h to 100,000 h
- Weight: 230 g
- Housing material: Plastic
- Mounting version: Surface mount
- Enclosure rating: IP54 (IEC 60529)
- Ambient operating temperature: –25 °C to +55 °C
- Storage temperature: –25 °C to +85 °C
- Dimensions (H x L x W): 70mm x 70mm x 70mm
- Weight: 0.23 kg
Key Features
- Positive action N/C contacts: 2
- N/O contacts: 1
- Emergency stop pushbutton is illuminable
- Obstruction protection included
- Rotary release type
- Labeling with "EMERGENCY STOP"
- Slow action switching element
- Surface mount version
- Protection class II (EN 50178)
- IP54 enclosure rating for dust and splash protection
Professional Installation Requirements
- Installation should be performed by a qualified electrician or safety system professional to ensure compliance with safety standards and proper wiring.
Applications
- Industrial machinery emergency stop control
- Safety systems requiring emergency stop functionality
- Surface mount installations in manufacturing environments
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable plastic housing extends product life reducing waste
- Low power consumption illumination reduces energy use
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK ES21-SA13H1 Emergency Stop Pushbutton Switch is available for immediate purchase, ideal for industrial safety and emergency stop applications.
