Emergency Stop Operator Head | Mushroom Actuator | IP66 Rated | Twist-Release Mechanism | @Pack of 1 | by Clipsal
The Emergency Stop Operator Head is designed for safety applications, featuring a large red mushroom actuator for high visibility and a twist-release reset mechanism. With an IP66 rating for dust and water resistance, it's perfect for industrial machinery, manufacturing plants, and automated production lines, ensuring compliance with international safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Emergency Stop Operator Head | Mushroom Actuator | IP66 Rated | Twist-Release Mechanism | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHZB5AS964
Alternatively Known As: Emergency Stop Button, E-Stop Head, Emergency Stop Switch, Mushroom Head Emergency Stop, Clipsal E-Stop
Technical Specifications
- Actuator type: Mushroom head, red
- Reset mechanism: Twist-release
- Mounting diameter: 22mm
- Degree of protection: IP66
- Material: High-impact plastic
- Operating temperature: -25°C to +70°C
- Mechanical durability: 300,000 cycles
- Dimensions (H x L x W): 40mm x 60mm x 40mm
- Weight: 0.12 kg
Key Features
- Robust emergency stop operator head for safety applications
- Large red mushroom actuator for high visibility
- Twist-release mechanism for reset
- IP66 rated for dust and water resistance
- Complies with international safety standards
- Easy installation in standard 22mm panel cutouts
Professional Installation Requirements
- Installation must be performed by a licensed electrician or qualified technician to ensure compliance with safety regulations.
Applications
- Industrial machinery emergency stop control
- Manufacturing plants
- Conveyor systems
- Automated production lines
- Electrical panels requiring emergency shutdown
Standards & Compliance
- Complies with AS/NZS 60947.5.1 for control circuit devices and switching elements
Environmental Benefits
- Enhances workplace safety, reducing risk of accidents and environmental hazards from uncontrolled machinery.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Emergency Stop Operator Head SCHZB5AS964 is available for immediate purchase. Ideal for industrial and commercial safety applications requiring reliable emergency stop functionality.
