Emit Deck Light 25mm 1W Tri-Colour 12/24V 1-Way White Domus
Domus Emit 25mm LED deck light, 1W, tri-colour, 36 deg beam, 12/24V DC, 1-way fascia, white. Requires 12/24V DC LED driver.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Emit-25-TRIO-WHT, Domus Emit Inground Light, Mini LED Deck Light, Tri-Colour Inground Light
Technical Specifications
- Power: 1W
- Input Voltage: 12/24V DC
- Colour Temperature: 3000K, 4000K or 5500K selectable
- Beam Angle: 36° standard; optional 19° and 60° lenses
- LED Type: CREE
- Colour Rendering Index: ≥90
- Luminous Output: 1.3 lm at 3000K, 4000K and 5500K
- Ingress Protection: IP67
- Impact Rating: IK10
- Dimming: No
- Expected LED Life: 50,000 hours
- Cut-Out: 19mm without cannister; 24mm with cannister
- Load Rating: 1500kg drive-over
- Driver Requirement: 12/24V DC constant-voltage LED driver, wired in parallel
- Finish: White
- Fascia: 1-way
- Dimensions (H x L x W): 43mm x 25mm x 25mm
- Weight: 0.1 kg
Key Features
- Compact 25mm diameter design for discreet deck, pathway and architectural lighting
- Selectable warm white, neutral white and cool white colour temperatures
- Standard 36° beam angle for focused feature illumination
- IP67-rated construction for outdoor and inground applications
- IK10 impact rating and 1500kg drive-over load rating
- Requires a separate 12/24V DC constant-voltage LED driver
- Optional beam lenses, honeycomb, linear lens and opal diffuser available
- 5-year replacement warranty stated on the manufacturer product page
Professional Installation Requirements
- Installation should be performed by a licensed electrician. Use a compatible 12/24V DC constant-voltage LED driver, wire fittings in parallel and follow the manufacturer's installation instructions. The driver and low-voltage cabling must be suitably selected for the installation environment.
Applications
- Residential and commercial deck lighting
- Outdoor pathways, stairs and steps
- Landscape and garden feature lighting
- Inground architectural lighting
- Drive-over lighting areas where the 1500kg load rating is suitable
Standards & Compliance
- Applicable to AS/NZS 60598.1 general requirements for luminaires
- Applicable to AS/NZS 60598.2.23:2021 requirements for extra-low-voltage lighting systems
Environmental Benefits
- 1W LED output supports low-energy feature lighting compared with higher-wattage conventional sources
- 50,000-hour rated LED life can reduce replacement frequency and associated waste
- IP67 and IK10 construction can support extended service life in outdoor applications
- LED technology avoids routine lamp replacement and reduces material consumption over the product life
Warranty Information
5-year replacement warranty stated by Domus Lighting for the EMIT-25 product series. Warranty eligibility is subject to Domus conditions, including installation by a licensed electrician and compliance with the installation instructions.
Available Now
Available through Domus Lighting and authorised Australian electrical and lighting distributors.
