Emit Deck Light LED 55mm RGBW 12/24V 4-Way White Fascia Domus
Domus Emit 55mm LED deck light, RGBW, 36 deg beam, 12/24V DC, 4-way fascia, white. Requires 12/24V DC LED driver.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Emit 55 RGBW Deck Light, Emit-55-RGBW-4WAY, 4-Way RGBW Inground Light, Recessed LED Deck Light
Technical Specifications
- Variant: EMIT-55-RGBW-4WAY
- Variant ID: 11543
- Light Source: CREE LED
- Power: 2.5W
- Input Voltage: 24V DC constant voltage
- Colour Output: RGBW
- Beam Angle: 36° standard; optional 19° and 60° lenses
- Ingress Protection: IP67
- Impact Protection: IK10
- Dimming: No
- Lifespan: 50,000 hours
- Load Rating: 1,500kg drive-over
- Cutout Diameter: 43mm without canister; 48mm with canister
- Installation Depth: Approximately 60–65mm without canister; 70mm with canister
- Required Accessories: 24V DC LED driver and RGBW colour controller
- Fascia: 4-way white
- Classification: Class III
- Dimensions (H x L x W): 62mm x 55mm x 55mm
- Weight: 0.25 kg
Key Features
- RGBW colour-changing LED output for feature and accent lighting
- Compact 55mm inground and deck-light format
- White 4-way fascia for directional light effects
- IP67-rated construction for suitable outdoor and inground applications
- IK10 impact rating and 1,500kg drive-over load rating
- 36° standard beam angle with optional 19° and 60° lens accessories
- 50,000-hour rated LED lifespan
- Requires parallel wiring to a 24V constant-voltage LED driver
- Requires a compatible RGBW colour controller
Professional Installation Requirements
- Installation must be performed by a licensed electrician. Connect to a suitable 24V DC constant-voltage LED driver and compatible RGBW controller, following the manufacturer's installation instructions and maintaining the IP67-rated cable connections.
Applications
- Residential and commercial deck lighting
- Landscape and garden feature lighting
- Pathway and stair lighting
- Architectural accent lighting
- Drive-over inground lighting where the 1,500kg load rating is suitable
Standards & Compliance
- AS/NZS 60598.1:2025 - applicable general safety requirements for luminaires; product-specific compliance declaration should be confirmed from the supplier or compliance documentation
Environmental Benefits
- Low 2.5W power consumption helps reduce operating energy use compared with higher-wattage feature lighting
- 50,000-hour rated LED lifespan can reduce replacement frequency and associated waste
- RGBW colour control allows lighting output and colour to be selected for the application, helping avoid unnecessary over-lighting
Warranty Information
5-year replacement warranty, subject to Domus Lighting warranty conditions. Warranty coverage requires installation by a licensed electrician and installation in accordance with the manufacturer's guidelines.
Available Now
Available through Domus Lighting and authorised Australian electrical and lighting distributors.
