Trade Discount 33%

Enclosed DOL Starter 12A 415V | IP65 Rated | Push-Button Control by Clipsal

BRAND: Clipsal
SKU: LE1D12N7S48
$104.90 List price: $157.40
+
Enclosed DOL starter with 12A operational current and 415V control circuit—ideal for industrial motor control applications. Built for durability, with IP65 protection and push-button control for ease of use.

Product Name/Title: TeSys LE, Enclosed DOL Starter, 1S 12A 415V 50/60

Brand: Clipsal

SKU: LE1D12N7S48

Alternatively Known As: DOL Starter, Direct On Line Starter, Motor Starter

Technical Specifications
  • Rated operational current: 12A AC-3
  • Control circuit voltage: 415V AC 50/60Hz
  • Motor power: Up to 7.5kW at 500V AC
  • Material: Polycarbonate
  • IP Rating: IP65
  • IK Rating: IK07
  • Ambient temperature range: -5 to 40 °C
  • Dimensions (H x L x W): 200mm x 153.5mm x 103mm
  • Weight: 1.015 kg
Key Features
  • Enclosed DOL starter with push-button control.
  • Rated operational current of 12A AC-3.
  • IP65 rated for protection against dust and water.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Motor control applications in various industrial settings.
Standards & Compliance
  • Complies with IEC 60947-4-1 for motor starters.
Environmental Benefits
  • Compliant with RoHS directive and free from toxic heavy metals.
Warranty Information

Standard warranty as per manufacturer guidelines.

Available Now

The TeSys LE Enclosed DOL Starter is available now for immediate purchase. Ideal for industrial motor control applications.

LE1D12N7S48 (LE1D12N7S48, 206 Kb) [Download]
