Enclosed Starter 2S 12A 415V | IP55 Rated | Thermal Overload Protection | by Clipsal
The Enclosed Starter 2S 12A 415V is designed for reliable motor control in industrial applications. With an IP55 rating for dust and water protection and a built-in thermal overload relay, it ensures safe operation for pumps, fans, and HVAC equipment. Ideal for licensed electricians, this robust starter simplifies installation and maintenance while enhancing energy efficiency.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Enclosed Starter 2S 12A 415V | IP55 Rated | Thermal Overload Protection | by Clipsal
Brand: Clipsal
SKU: SCHLE2D12N7
Alternatively Known As: motor starter, enclosed motor starter, Clipsal starter, 12A starter, 415V starter, SCHLE2D12N7
Technical Specifications
- Rated operational voltage: 415V AC
- Rated current: 12A
- Number of poles: 2 (2S)
- Enclosure rating: IP55
- Thermal overload relay included
- Frequency: 50Hz
- Ambient temperature: -5°C to +40°C
- Mounting: Surface
- Dimensions (H x L x W): 220mm x 140mm x 120mm
- Weight: 2.5 kg
Key Features
- Robust enclosed starter for enhanced safety
- 12A current rating suitable for a wide range of motors
- 415V operational voltage
- 2-pole (2S) configuration
- IP55 rated enclosure for dust and water protection
- Thermal overload protection
- Easy installation and maintenance
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules and local regulations.
Applications
- Industrial motor control
- Pumps and fans
- Conveyor systems
- HVAC equipment
- General machinery requiring reliable motor starting and protection
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances energy efficiency by providing reliable motor control
- Reduces risk of electrical faults and associated waste
- Durable construction minimizes replacement frequency
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Enclosed Starter 2S 12A 415V (SCHLE2D12N7) is available for immediate purchase. Ideal for industrial and commercial motor control applications.
