Ex-Certified 150A 4P Gland Bracket | 660V Voltage | IP55 Ingress Protection | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS2492

$2,191.80 List price: $2,722.20

+ −

30 Days Return Delivery Options

Ex-certified 150A 4P gland bracket designed for 660V applications, featuring IP55 ingress protection and quick release functionality. Ideal for mining and tunnelling, this durable stainless steel connector ensures reliable performance in hazardous environments.

Description

Product Name/Title: PS 660V 150A 4P Gland Bracket (270) 95-C 55-60-G (241.1)

Brand: Ausproof

SKU: RS2492

Alternatively Known As: Ex-certified 150A 4P Gland Bracket, PS Range 660V Plug and Receptacle, Flameproof Electrical Connector

Technical Specifications

Voltage: 660 to 1,100V
Current: 150A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 12.5kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 4.0kA for 0.2 seconds
AC HV Withstand (Phase): 4.2kV for one minute
AC HV Withstand (Pilot): 1.0kV for one minute
Temperature Rise: 150A
Compliant to: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 95mm x 241mm x 270mm
Weight: 7.9 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by a qualified electrician experienced with Ex-certified equipment and hazardous area installations.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Flameproof repairable design minimizes waste by allowing on-site body casting replacement.

Warranty Information

Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.

Available Now

The Ausproof PS 660V 150A 4P Gland Bracket is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
