PL 1100V 300A 6P Plug (90) 50-C 45-50-G (245.1)

Ex Certified 300A 6P Plug | Quick Release & IP55 Rated | Stainless Steel by Ausproof

BRAND: Ausproof

SKU: RS2182

$1,611.50 List price: $2,001.50

+ −

30 Days Return Delivery Options

The Ex Certified 300A 6P Plug features quick release functionality and IP55 ingress protection—ideal for mining and hazardous environments. Built for commercial applications, it offers durable stainless steel construction and easy termination for reliable electrical connections.

Description

Product Name/Title: PL 1100V 300A 6P Plug (90) 50-C 45-50-G (245.1)

Brand: Ausproof

SKU: RS2182

Alternatively Known As: PL Range 6 Pin Plug, Ex Certified Mining Plug, Flameproof Industrial Plug, Quick Release 300A Plug

Technical Specifications

Operating Voltage: 660V to 3300V
Current Rating: 300A to 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC HV Withstand (Phase): 8.6kV for one minute
AC HV Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Weight: 9.0 kg
Dimensions (H x L x W): 300mm x 250mm x 200mm
Weight: 9.0 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by a qualified electrician experienced with Ex-certified equipment and hazardous area installations.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Easy on-site repair reduces waste and downtime.

Warranty Information

Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.

Available Now

The Ausproof PL 1100V 300A 6P Plug is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring robust and certified electrical connections.
