Home/Solar/Solar Panels/Ex-Certified Quick Release Plug | 660V 300A | IP55 Rated | Stainless Steel by Ausproof

Trade Discount 19%

Ex-Certified Quick Release Plug | 660V 300A | IP55 Rated | Stainless Steel by Ausproof

BRAND: Ausproof

SKU: RS2462QR

$3,737.30 List price: $4,641.70

+ −

30 Days Return Delivery Options

Ex-certified quick release plug with 660V and 300A rating—ideal for mining and hazardous environments. Built for durability with stainless steel construction and IP55 ingress protection, ensuring reliable performance in tough conditions.

Description

Product Name/Title: PL B2B QR 660V 300A 4P Full Assembly

Brand: Ausproof

SKU: RS2462QR

Alternatively Known As: PL Range Quick Release Plug, Ex-certified 660V 300A Plug, Flameproof Electrical Plug Assembly

Technical Specifications

Voltage: 660 to 3300V
Current Rating: 300 to 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 Tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 Tests of 8.0kA for 0.2 seconds
AC HV Withstand (Phase): 8.6kV for one minute
AC HV Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Plug Weight: 9.0 KG
Receptacle Weight: 10.7 KG
Dimensions (H x L x W): 300mm x 400mm x 250mm
Weight: 9 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by a qualified electrician experienced with Ex-certified equipment and hazardous area installations.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Easy on-site flameproof repair reduces waste and downtime.

Warranty Information

Standard manufacturer warranty applies. Please contact Ausproof for detailed warranty terms.

Available Now

The Ausproof PL B2B QR 660V 300A 4P Full Assembly is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
