Ex-rated 1100V 300A 4P Connector | Quick Release & IP55 Rated | Flameproof by Ausproof

BRAND: Ausproof

SKU: RS2464

$2,887.50 List price: $3,586.30

+ −

30 Days Return Delivery Options

The Ex-rated 1100V 300A 4P connector features quick release and IP55 ingress protection—ideal for mining and hazardous environments. Built for safety and durability, with stainless steel construction and easy flameproof repair.

Description

Product Name/Title: PL B2B 1100V 300A 4P Full Assembly

Brand: Ausproof

SKU: RS2464

Alternatively Known As: PL Range Plug and Receptacle Assembly, Ex-rated 1100V 300A 4-pin Connector, Flameproof Electrical Connector

Technical Specifications

Operating Voltage: 660V to 3300V
Current Rating: 300A to 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC HV Withstand (Phase): 8.6kV for one minute
AC HV Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Plug Weight: 9.0 kg
Receptacle Weight: 10.7 kg
Dimensions (H x L x W): 300mm x 400mm x 200mm
Weight: 9 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation should be performed by qualified electricians trained in hazardous area electrical equipment to ensure compliance with safety standards.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Easy flameproof repair reduces waste by allowing component replacement instead of full unit replacement.

Warranty Information

Warranty details available upon request from Ausproof, typically covering manufacturing defects.

Available Now

The Ausproof PL B2B 1100V 300A 4P Full Assembly is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial environments requiring robust and flameproof electrical connections.
