Trade Discount 19%
Ex RGB Assembly 4 Pin 60A 660V IP55 Restrained 6mm² Ausproof
Ausproof Ex RGB Assembly features 4 Pin, 60A, 660V and IP55. Ideal for mining and tunnelling hazardous-area power.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Operating Voltage: 660-1,100V
- Current Rating: 60A Ex, 90A Non Ex
- Material: Grade 304 Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 3.2kA for 0.2 seconds (2 tests)
- Through Fault Current (Earth): 1.0kA for 0.2 seconds (2 tests)
- AC HV Withstand (Phase): 4.2kV for one minute
- AC HV Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: Suitable for 60A and 90A
- Weight: 5.0 kg (Receptacle), 2.6 kg (Plug)
- Dimensions (H x L x W): 150mm x 250mm x 200mm
- Weight: 5 kg
Key Features
- A single solid earth body
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone protection cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Professional installation by qualified personnel trained in Ex-rated equipment is required to ensure safety and compliance.
Applications
- Mining
- Tunnelling
- Commercial applications
- Group 1 hazardous environments
Standards & Compliance
- Complies with AS/NZS 1299 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacements.
- Flameproof design enhances safety, reducing risk of environmental hazards.
Warranty Information
Standard manufacturer warranty applies. Please contact Ausproof for detailed warranty terms.
Available Now
The Ausproof PES 660V 60A 4P Gland Bracket is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial environments.
