Extreme Temperature Galvanised Steel Conduit | -60 to +150°C | UV Stabilised TPV Jacket | 20mm by Cabac
The Cabac CONDUIT CEXT Extreme Temperature Galvanised Steel TPV NC20X25M is a heavy-duty flexible conduit designed for excellent cable protection and resistance to extreme temperatures from -60 to +150°C, suitable for indoor and outdoor use.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: CONDUIT CEXT EXTREME TEMPERATURE GALVANISED STEEL TPV NC20X25M
Brand: Cabac
SKU: CETX20
Alternatively Known As: High Temperature Flexible Steel Conduit, Galvanised Steel Spiral Conduit, TPV Jacketed Conduit, Extreme Temperature Cable Conduit
Technical Specifications
- Material: Galvanised steel core with TPV jacket
- Temperature rating: -60 to +150 degrees Celsius
- Nominal size: 20mm
- Trade size: 1/2 inch
- Inner Diameter (ID): 16mm
- Outer Diameter (OD): 21.1mm
- Minimum Bend Radius: 65mm
- Length: 25m
- Dimensions (H x L x W): 21mm x 25000mm x 21mm
- Weight: 2.5 kg
Key Features
- Heavy-duty spiral wound, interlocked galvanised steel core for superior strength and flexibility
- UV stabilised thermoplastic vulcanizate (TPV) jacket providing liquid tight conduit and high temperature resistance
- Halogen free and corrosion resistant
- Compression resistant to HD rating of 1250 Newtons
- IP66 rated when used with CABFLX fittings
Professional Installation Requirements
- Installation should be performed by a qualified electrician or professional experienced with flexible metallic conduits to ensure compliance with electrical safety standards.
Applications
- Indoor and outdoor cable installation projects requiring flexibility and mechanical protection
- Environments with exposure to extreme temperatures ranging from -60 to +150 degrees Celsius
- Cable protection in industrial, commercial, and infrastructure settings
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen free construction reduces harmful emissions in case of fire
- Durable materials extend product life and reduce replacement frequency
- UV stabilised jacket enhances longevity in outdoor environments
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.
Available Now
The Cabac CONDUIT CEXT Extreme Temperature Galvanised Steel TPV NC20X25M is available for immediate purchase, ideal for cable protection in extreme temperature environments.
