Fast-Acting Glass Fuse 2A | 250 Vac Voltage Rating | Non-Indicating | Ferrule Connection by Eaton

BRAND: Eaton
SKU: BK-AGC-2-R
$0.60 List price: $0.70
+ −
30 Days Return Delivery Options
Fast-acting glass fuse with a 2A rating and 250 Vac voltage—ideal for electronic circuits requiring reliable protection. Built for safety compliance, this non-indicating fuse features a ferrule end connection for easy installation.

Product Name/Title: Fast-Acting Glass Fuse 2A | 250 Vac Voltage Rating | Non-Indicating | Ferrule Connection by Eaton

Brand: Eaton

SKU: BK-AGC-2-R

Alternatively Known As: Fast-acting glass fuse, AGC fuse, 2A fuse, electronic fuse

Technical Specifications
  • Amperage Rating: 2 A
  • Voltage Rating: 250 Vac, 32 Vdc (self certified)
  • Interrupt Rating: 100 AIC at 250 Vac, 10 kAIC at 125 Vac
  • Fuse Indicator: Non-indicating
  • Connection Type: Ferrule end x ferrule end
  • Response Time: 60 min at 135%, 120 sec at 200%
  • Type: Electronic
  • Dimensions (H x L x W): 6.35mm x 31.75mm x 6.35mm
  • Weight: 0.0023 kg
Key Features
  • Fast-acting glass tube fuse
  • 2 Ampere rating
  • Voltage rating: 250 Vac, 32 Vdc (self certified)
  • Interrupt rating: 100 AIC at 250 Vac, 10 kAIC at 125 Vac
  • Non-indicating fuse
  • Ferrule end x ferrule end connection
  • Response time: 60 min at 135%, 120 sec at 200%
Professional Installation Requirements
  • Installation by a qualified electrician is recommended to ensure proper fuse selection and safety compliance.
Applications
  • Electronic circuits requiring fast-acting fuse protection
Standards & Compliance
  • Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
  • RoHS compliant ensuring reduced hazardous substances
  • CE marked for safety and environmental standards
Warranty Information

Standard manufacturer warranty applies; please refer to Eaton for details.

Available Now

The Eaton Bussmann AGC Series Fast-Acting Glass Tube Fuse 2A 250Vac is available for immediate purchase, ideal for electronic circuit protection applications.
