Fiber Amplifier WLL180T-N434 | 650 nm LED Light Source | IP50 Rated | by SICK
The Fiber Amplifier WLL180T-N434 features a visible red LED light source with a 650 nm wavelength, making it ideal for industrial automation and machine safety applications. With a robust plastic housing and an IP50 enclosure rating, this stand-alone fiber-optic amplifier ensures high shock and vibration resistance, perfect for object detection in manufacturing processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Fiber Optic Amplifier, Fiber Amplifier Sensor, Optical Fiber Amplifier, SICK Fiber Sensor
Technical Specifications
- Supply voltage: 12 V DC to 24 V DC
- Current consumption: ≤ 50 mA
- Protection class: III
- Digital output: 1 NPN, light/dark switching, manually selectable
- Response time: ≤ 16 µs
- Switching frequency: 31.2 kHz
- Delay time: Programmable 0 ms to 9,999 ms
- Housing material: Plastic ABS/PC
- Connection: Male M8, 4-pin connector
- Enclosure rating: IP50
- Operating temperature: -25°C to +55°C
- Storage temperature: -40°C to +70°C
- Shock resistance: 50 g, 11 ms
- Vibration resistance: 10 Hz to 55 Hz, amplitude 1 mm
- EMC: EN 60947-5-2
- LED wavelength: 650 nm
- LED average service life: 100,000 hours at 25°C
- Dimensions (H x L x W): 35mm x 72mm x 11mm
- Weight: 0.1 kg
Key Features
- Stand-alone fiber-optic amplifier
- Visible red LED light source with 650 nm wavelength
- Free LED risk group according to EN 62471 and IEC 62471
- Adjustable sensing range depending on optical fiber cable used
- Digital output with NPN type and light/dark switching
- Programmable delay time from 0 ms to 9,999 ms
- Robust plastic ABS/PC housing
- Male M8 4-pin connector
- High shock and vibration resistance
- IP50 enclosure rating
- Operating temperature range from -25°C to +55°C
- Complies with EMC standard EN 60947-5-2
- RoHS compliant
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with fiber-optic sensor systems and electrical safety standards.
Applications
- Industrial automation for fiber-optic sensing
- Machine safety and monitoring
- Object detection in manufacturing processes
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with ≤ 50 mA current draw
- Long LED service life of 100,000 hours reduces waste
- RoHS compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WLL180T-N434 Fiber Amplifier is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
