Fiber Optic Amplifier Expansion Unit WLL180T-E232 | LED Light Source | IP50 Rated | by SICK
The Fiber Optic Amplifier Expansion Unit WLL180T-E232 features a visible red LED light source and is designed for industrial automation applications. With a high switching frequency of up to 31.2 kHz and robust IP50 protection, this unit is perfect for object detection and sensing in various environments. Its long LED service life of 100,000 hours ensures reliability and efficiency, making it an ideal choice for fiber-optic sensor systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Device type: Fiber-optic amplifier expansion unit
- Light source: LED, visible red light at 650 nm wavelength
- Average LED service life: 100,000 hours at 25°C
- Supply voltage: 12 V DC to 24 V DC
- Current consumption: ≤ 50 mA
- Digital output: 1 NPN output, light/dark switching, manually selectable
- Switching frequency: up to 31.2 kHz
- Response time: ≤ 16 µs
- Protection class: III
- Enclosure rating: IP50
- Operating temperature: -25°C to +55°C
- Storage temperature: -40°C to +70°C
- Housing material: Plastic ABS/PC
- Cable: 2-wire, 2 m length, PVC insulation
- Shock resistance: 50 g, 11 ms
- Vibration resistance: 10 Hz to 55 Hz, amplitude 1 mm
- Dimensions (H x L x W): 35mm x 72mm x 11mm
- Weight: 0.1 kg
Key Features
- Fiber-optic amplifier expansion unit with visible red LED light source
- Adjustable sensing range depending on optical fiber cable used
- LED status indicators for digital output and sensor functions
- Programmable delay time from 0 ms to 9,999 ms
- High switching frequency up to 31.2 kHz with light/dark switching mode
- Robust plastic ABS/PC housing with IP50 protection rating
- Wide ambient operating temperature range from -25°C to +55°C
- Protection class III with reverse polarity, overcurrent, and short-circuit protection
- Comes with BEF-WLL180 mounting bracket
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with fiber-optic sensor systems and electrical safety standards.
Applications
- Industrial automation for object detection and sensing
- Expansion unit for fiber-optic sensor systems
- Use in environments requiring visible red light sensing
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with efficient LED light source
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- RoHS compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WLL180T-E232 Fiber-optic Amplifier Expansion Unit is available for immediate purchase, ideal for industrial automation and sensing applications.
