Fiber Optic Amplifier GLL170-N334 | IP66 Rated | 2 kHz Switching Frequency | Adjustable Sensing Range | by SICK
The Fiber Optic Amplifier GLL170-N334 is designed for industrial automation, featuring a robust IP66-rated housing and a high switching frequency of up to 2 kHz. With adjustable sensing range and a visible red LED light source, it's perfect for object detection and machine safety applications. Built for reliability in harsh environments, this amplifier ensures optimal performance and compliance with safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 30 mA
- Protection class: III
- Digital output: 1 NPN output with light/dark switching
- Output current max: ≤ 100 mA
- Switching frequency: 2 kHz
- Response time: ≤ 250 µs
- Enclosure rating: IP66
- Operating temperature: -25 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Shock resistance: 50 g, 11 ms
- Vibration resistance: 10 Hz to 55 Hz, amplitude 1 mm
- Connection: Male M8, 4-pin connector
- Housing material: Plastic (PC/POM)
- Cable: Plastic, PVC, diameter 3.8 mm
- Dimensions (H x L x W): 31.7mm x 72.5mm x 10mm
- Weight: 0.1 kg
Key Features
- Stand-alone fiber-optic amplifier
- Visible red LED light source with 632 nm wavelength
- LED risk group marking: Free group
- Adjustable sensing range, switching mode, and switch-off delay via potentiometer
- LED indicators for power and digital output status
- High switching frequency up to 2 kHz with response time ≤ 250 µs
- Reverse polarity, overcurrent, and short-circuit protected outputs
- Robust plastic housing with IP66 rating for harsh environments
- Wide ambient operating temperature range from -25 °C to +55 °C
- Shock resistance of 50 g and vibration resistance compliant with EN standards
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with fiber-optic sensor systems to ensure proper setup and safety compliance.
Applications
- Industrial automation for object detection
- Machine safety and control systems
- Optical sensing in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with efficient LED light source
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- RoHS compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK GLL170-N334 Fiber-optic Amplifier is available for immediate purchase, ideal for industrial automation and safety control applications.
