Fiber Optic Amplifier SICK GLL170-N332 | IP66 Rated | 632 nm LED Light Source | NPN Digital Output | by SICK
The SICK GLL170-N332 Fiber Optic Amplifier features a visible red LED light source with a 632 nm wavelength and an IP66 enclosure rating, making it perfect for industrial automation and safety control applications. With a fast response time of ≤ 250 µs and a switching frequency of 2 kHz, this amplifier is designed for reliable object detection and machine safety. Ideal for professionals in automation and quality control, it ensures efficient performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 30 mA
- Protection class: III
- Digital output type: 1 NPN, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 250 µs
- Switching frequency: 2 kHz
- LED wavelength: 632 nm
- Operating temperature: -25 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Enclosure rating: IP66
- Cable: 3-wire, 2 m length, Ø 3.8 mm
- Housing material: Plastic (PC/POM)
- EMC standard: EN 60947-5-2
- Dimensions (H x L x W): 31.7mm x 72.5mm x 10mm
- Weight: 0.1 kg
Key Features
- Stand-alone fiber-optic amplifier
- Visible red LED light source with 632 nm wavelength
- LED risk group marking: Free group
- Potentiometer for setting sensing range, switching mode, and switch-off delay
- LED indicators for power and digital output status
- Digital output: 1 NPN, light/dark switching
- Short-circuit, overcurrent, and reverse polarity protected outputs
- Response time ≤ 250 µs and switching frequency 2 kHz
- Housing made of plastic (PC/POM) with IP66 rating
- Operating temperature range from -25 °C to +55 °C
- Shock resistance 50 g and vibration resistance 10 Hz to 55 Hz
- Cable connection with 3-wire, 2 m length
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with fiber-optic sensor systems and electrical safety standards.
Applications
- Industrial automation for object detection
- Machine safety and control systems
- Material handling and packaging lines
- Quality control and inspection systems
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- Energy-efficient LED light source minimizes power consumption
- RoHS compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK GLL170-N332 Fiber-optic Amplifier is available for immediate purchase, ideal for industrial automation and safety control applications.
