Fiber Optic Amplifier SICK GLL170-N333 | IP66 Rated | 632 nm LED Light | by SICK
The Fiber Optic Amplifier SICK GLL170-N333 is designed for industrial automation, featuring a visible red LED light source at 632 nm and an IP66 rating for dust and water resistance. With a fast response time of ≤ 250 µs and a switching frequency of up to 2 kHz, it’s perfect for precise object detection and machine safety applications. Built for reliability, this stand-alone device ensures optimal performance in various environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 30 mA
- Protection class: III
- Digital output type: 1 NPN, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 250 µs
- Switching frequency: 2 kHz
- Delay time: selectable 0 ms to 40 ms via rotary switch
- Housing material: Plastic (PC/POM)
- Connection: M8 connector, 3-pin
- Enclosure rating: IP66
- Operating temperature: -25 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Shock resistance: 50 g, 11 ms
- Vibration resistance: 10 Hz to 55 Hz, amplitude 1 mm
- LED wavelength: 632 nm
- Average LED service life: 100,000 hours at 25 °C
- Dimensions (H x L x W): 31.7mm x 72.5mm x 10mm
- Weight: 0.1 kg
Key Features
- Stand-alone fiber-optic amplifier device
- Visible red LED light source with 632 nm wavelength
- LED risk group marking: Free group
- Adjustable sensing range, switching mode, and switch-off delay via potentiometer
- LED indicators for power and digital output status
- Digital output: 1 NPN, light/dark switching mode
- Short-circuit, overcurrent, and reverse polarity protected outputs
- Response time ≤ 250 µs and switching frequency up to 2 kHz
- Housing made of plastic (PC/POM) with IP66 rating
- Operating temperature range from -25 °C to +55 °C
- Shock resistance 50 g and vibration resistance 10 Hz to 55 Hz
- RoHS compliant and multiple international conformity certificates
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with fiber-optic sensor systems and electrical safety standards.
Applications
- Industrial automation for object detection
- Machine safety and control systems
- Quality control in manufacturing processes
- Automation requiring precise sensing with fiber-optic cables
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with efficient LED light source
- Long LED service life of approximately 100,000 hours reduces waste
- RoHS compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK GLL170-N333 Fiber-optic Amplifier is available for immediate purchase, ideal for industrial automation and sensing applications requiring reliable fiber-optic amplification.
