Fiber Optic Amplifier WLL180T-M674 | Infrared LED 1450 nm | Adjustable PNP Outputs | IP50 Rated | by SICK
The Fiber Optic Amplifier WLL180T-M674 is designed for industrial automation, featuring an infrared LED light source with a 1450 nm wavelength and two adjustable PNP digital outputs for light/dark switching. With a fast response time of ≤ 16 µs and a robust IP50-rated housing, this amplifier is perfect for machine safety and process control applications, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Device type: Fiber-optic amplifier base unit
- Light source: Infrared LED, wavelength 1450 nm
- Supply voltage: 12 V DC to 24 V DC with ≤ 10% ripple
- Current consumption: ≤ 50 mA
- Digital outputs: 2 PNP, individually adjustable, light/dark switching
- Switching frequency: up to 31.2 kHz
- Response time: ≤ 16 µs
- Time functions: Without time delay, off delay, switch-on delay, ON and OFF delay, one shot
- Housing material: Plastic ABS/PC
- Connection: Male M8, 4-pin connector
- Protection class: III
- Enclosure rating: IP50
- Operating temperature: -25 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Shock resistance: 50 g, 11 ms
- Vibration resistance: 10 Hz to 55 Hz, amplitude 1 mm
- EMC standard: EN 60947-5-2
- LED risk group: Free group
- Average LED service life: 100,000 hours at 25 °C
- Dimensions (H x L x W): 35mm x 72mm x 11mm
- Weight: 0.1 kg
Key Features
- Fiber-optic amplifier base unit with adjustable sensor parameters
- Infrared LED light source with 1450 nm wavelength
- Two individually adjustable PNP digital outputs with light/dark switching
- Fast response time ≤ 16 µs and programmable delay time up to 9,999 ms
- Robust plastic ABS/PC housing with IP50 protection rating
- Wide ambient operating temperature range from -25 °C to +55 °C
- High shock and vibration resistance for industrial environments
- LED indicators for switching output status
- Complies with photobiological safety standards (EN 62471)
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with fiber-optic sensor systems and electrical safety standards.
Applications
- Industrial automation for object detection
- Machine safety and monitoring
- Process control with fiber-optic sensors
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with supply voltage of 12 V DC to 24 V DC
- Long LED service life of 100,000 hours reduces waste and replacement frequency
- RoHS compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WLL180T-M674 Fiber-optic Amplifier Base Unit is available for immediate purchase, ideal for industrial automation and sensing applications.
