Fiber Optic Cable LL3-TV05 | Threaded Sleeve Design | 90° Deflection | 3600mm Sensing Range | by SICK
The Fiber Optic Cable LL3-TV05 features a threaded sleeve design and 90° deflection, making it ideal for standard fiber-optic sensing applications. With a maximum sensing range of 3,600 mm and a minimal object detection diameter of just 0.4 mm, this cable is built for precision in industrial automation. Its durable materials ensure a long service life, reducing waste and maintenance frequency.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Fiber optic cable LL3-TV05, SICK fiber optic sensor cable, Threaded sleeve fiber optic cable, 90 degree deflection fiber optic cable
Technical Specifications
- Device type: Fiber-optic cables
- Functional principle: Through-beam system with sender and receiver
- Fiber-optic head design: Threaded sleeve, 90° deflection
- Compatible fiber-optic amplifiers: GLL70, WLL80, WLL180, GLL170(T), WLL24 Ex
- Sensing range max.: 3,600 mm (depending on amplifier and operating mode)
- Minimal object diameter: 0.4 mm
- Angle of dispersion: 16°
- Integrated lens: Yes
- Compatibility tip adapters: No
- Compatibility with infrared light: No
- Optical fiber cable can be shortened: Yes
- Adapter end sleeves required: No
- Optical fiber head material: Polyamid (PA)
- Light emission: Radial
- Thread diameter (housing): M4
- Fiber length: 2,000 mm
- Bending radius: 25 mm
- Dynamic flexibility (robotics): No
- Outside diameter, optical fiber cable connection: 2.2 mm
- Core structure diameter: 1 mm
- Sheath material: Polyethylene (PE)
- Fibers material: Polymethylmethacrylate (PMMA)
- Ambient operating temperature: -40 °C to +70 °C
- Dimensions (H x L x W): 10mm x 50mm x 10mm
- Weight: 0.1 kg
Key Features
- Through-beam system consisting of a sender and a receiver
- Fiber-optic head with threaded sleeve and 90° deflection
- Maximum sensing range up to 3,600 mm depending on amplifier and operating mode
- Minimal object detection diameter of 0.4 mm
- Optical fiber head with 16° angle of dispersion and integrated lens
- Optical fiber cable can be shortened without adapter end sleeves
- Radial light emission with M4 thread diameter housing
- Fiber length of 2,000 mm with 25 mm bending radius
- Materials include Polyamid (PA) for head, Polyethylene (PE) sheath, and Polymethylmethacrylate (PMMA) fibers
- Operating temperature range from -40 °C to +70 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper connection with compatible fiber-optic amplifiers and secure mounting using included hardware.
Applications
- Standard fiber-optic sensing applications requiring through-beam systems
- Compatible with fiber-optic amplifiers GLL70, WLL80, WLL180, GLL170(T), WLL24 Ex
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable materials and long service life reduce waste and replacement frequency
- Energy-efficient sensing reduces power consumption in automation systems
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK LL3-TV05 fiber-optic cable is available for immediate purchase, ideal for industrial automation and sensing applications requiring precise through-beam detection.
