Fiber Optic Cable LL3-TV06 | Through-Beam System | 90° Deflection | Heat-Resistant | by SICK
The LL3-TV06 fiber optic cable is designed for industrial sensing applications, featuring a through-beam system with a sender and receiver. With a 90° deflection and heat resistance up to 100°C, this cable ensures reliable performance in extreme environments, making it ideal for precise detection in various industrial settings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Device type: Fiber-optic cables
- Functional principle: Through-beam system with sender and receiver
- Fiber-optic head design: Threaded sleeve, 90° deflection
- Sensing range max: 3,180 mm with WLL80 at 8 ms
- Minimal object diameter: 0.4 mm
- Angle of dispersion: 18.18°
- Integrated lens: Yes
- Compatibility tip adapters: No
- Compatibility with infrared light: No
- Optical fiber cable can be shortened: Yes
- Light emission: Radial
- Thread diameter (housing): M4
- Fiber length: 2,000 mm
- Bending radius: 25 mm
- Dynamic flexibility (robotics): No
- Outside diameter, optical fiber cable connection: 2.2 mm
- Material: Optical fiber head - Polyamide (PA), Sheath - Polyethylene (PE), Fibers - Polymethylmethacrylate (PMMA)
- Ambient operating temperature: -40 °C to +105 °C
- Dimensions (H x L x W): 10mm x 2000mm x 10mm
- Weight: 0.1 kg
Key Features
- Through-beam system consisting of a sender and a receiver
- Fiber-optic head with threaded sleeve and 90° deflection
- Heat-resistant up to ≥100°C
- Compatible with multiple fiber-optic amplifiers
- Optical fiber head with 18.18° angle of dispersion and integrated lens
- Optical fiber cable can be shortened without adapter end sleeves
- Radial light emission from polyamide (PA) optical fiber head
- Fiber length of 2,000 mm with 25 mm bending radius
- Sheath made of polyethylene (PE) and fibers made of polymethylmethacrylate (PMMA)
Professional Installation Requirements
- Installation by trained personnel recommended to ensure proper connection with compatible fiber-optic amplifiers and secure mounting.
Applications
- Industrial sensing applications requiring heat-resistant fiber-optic cables
- Use with compatible fiber-optic amplifiers WLL80, WLL180, GLL170(T), WLL24 Ex
- Environments with ambient operating temperatures from -40°C to +105°C
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable materials and heat resistance reduce replacement frequency and waste
- Supports energy-efficient sensing systems by enabling precise detection
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK LL3-TV06 fiber-optic cable is available for immediate purchase, ideal for industrial sensing applications requiring heat-resistant and precise fiber-optic solutions.
