Fibre Patch Lead LC/LC Duplex OM4 50U | 0.5m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
The Fibre Patch Lead LC/LC Duplex OM4 50U is designed for high-speed data transmission, featuring a 0.5m length and low insertion loss for optimal performance. Ideal for data centres and enterprise networking, this patch lead ensures secure connections with its durable LSZH jacket and 50/125µm core diameter, making it perfect for short-distance patching.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead LC/LC Duplex OM4 50U | 0.5m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-LCLCOM4-0
Alternatively Known As: OM4 LC to LC Fibre Patch Lead, LC/LC Duplex Fibre Optic Cable, OM4 50/125 Multimode Patch Cord, 0.5m Fibre Jumper
Technical Specifications
- Connector Type: LC to LC Duplex
- Fibre Type: OM4 Multimode 50/125µm
- Length: 0.5m
- Jacket: LSZH (Low Smoke Zero Halogen)
- Insertion Loss: ≤0.3dB
- Return Loss: ≥30dB
- Core Diameter: 50µm
- Cladding Diameter: 125µm
- Colour: Aqua
- Operating Temperature: -20°C to +70°C
- RoHS Compliant
- Dimensions (H x L x W): 3mm x 500mm x 3mm
- Weight: 0.1 kg
Key Features
- OM4 multimode fibre for high-speed data transmission
- LC to LC duplex connectors for secure and reliable connections
- Low insertion loss and high return loss
- 0.5 metre length for short-distance patching
- 50/125µm core diameter for optimal performance
- Flexible and durable jacket for easy installation
Professional Installation Requirements
- Installation by a qualified network technician is recommended to ensure optimal performance and compliance with network standards.
Applications
- Data centres
- Telecommunications rooms
- Enterprise networking
- High-speed LAN and SAN environments
- Server connections
- Switch-to-switch links
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Supports high-speed data transfer, reducing the need for multiple cables and minimising electronic waste.
- Low power loss helps optimise energy efficiency in network infrastructure.
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Repelec LC/LC Duplex OM4 50U 0.5m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centre and enterprise network applications.
