Fibre Patch Lead LC/LC Duplex OM4 50U | 10m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
The Fibre Patch Lead LC/LC Duplex OM4 50U is designed for high-speed data transmission, featuring a 10m length and low insertion loss for optimal performance. Ideal for data centres and enterprise networking, this patch lead supports 10/40/100Gbps Ethernet applications, ensuring reliable connections in telecommunications environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead LC/LC Duplex OM4 50U | 10m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-LCLCOM4-10
Alternatively Known As: OM4 LC to LC Fibre Patch Lead, 10m Duplex Fibre Optic Cable, LC/LC Multimode Patch Cord, OM4 50/125 Fibre Lead
Technical Specifications
- Connector Type: LC to LC Duplex
- Fibre Type: OM4 50/125µm multimode
- Cable Length: 10 metres
- Jacket Type: LSZH (Low Smoke Zero Halogen)
- Insertion Loss: ≤0.3dB
- Return Loss: ≥30dB
- Bandwidth: 4700 MHz·km (at 850nm)
- Supports 10/40/100Gbps Ethernet
- Colour: Aqua
- Dimensions (H x L x W): 6mm x 10000mm x 3mm
- Weight: 0.15 kg
Key Features
- 10 metre length for extended reach
- OM4 50/125µm multimode fibre for high-speed data transmission
- LC to LC duplex connectors for secure, low-loss connections
- Low insertion loss and high return loss
- Suitable for 10/40/100Gbps Ethernet applications
- Flexible and durable jacket for easy installation
Professional Installation Requirements
- Installation by a qualified network technician is recommended to ensure optimal performance and compliance with network standards.
Applications
- Data centres
- Enterprise networking
- Telecommunications rooms
- Server rooms
- High-speed backbone connections
- SAN (Storage Area Network) environments
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Supports high-speed data transmission, reducing the need for multiple cables and minimizing electronic waste.
- Low power loss helps improve network efficiency.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Repelec LC/LC Duplex OM4 50U 10m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centre, enterprise, and telecommunications applications.
