Fibre Patch Lead LC/LC Duplex OM4 50U | 30m Length | High-Speed Data Transmission | Aqua Color | @Pack by Repelec
The Fibre Patch Lead LC/LC Duplex OM4 50U is designed for high-speed data transmission, featuring a 30m length and LC to LC duplex connectors. Ideal for data centres and enterprise networking, this patch lead ensures low insertion loss and high return loss, making it perfect for 10/40/100Gbps Ethernet applications. Built with ultra bend-insensitive fibre, it offers flexibility in installation while maintaining optimal performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead LC/LC Duplex OM4 50U | 30m Length | High-Speed Data Transmission | Aqua Color | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-LCLCOM4-30
Alternatively Known As: OM4 fibre patch lead, LC to LC duplex fibre cable, 30m multimode fibre optic cable, OM4 LC patch cord, high-speed fibre jumper
Technical Specifications
- Connector Type: LC/LC Duplex
- Fibre Type: OM4 Multimode 50/125μm
- Length: 30 metres
- Insertion Loss: ≤0.3dB
- Return Loss: ≥30dB
- Jacket Material: LSZH (Low Smoke Zero Halogen)
- Bandwidth: 4700 MHz·km (at 850nm)
- Operating Temperature: -20°C to +70°C
- Colour: Aqua
- Dimensions (H x L x W): 6mm x 30000mm x 3mm
- Weight: 0.15 kg
Key Features
- 30 metre length for extended reach
- OM4 multimode fibre for high-speed data transmission
- LC to LC duplex connectors for secure and reliable connections
- Low insertion loss and high return loss
- Suitable for 10/40/100Gbps Ethernet applications
- Ultra bend-insensitive fibre for flexible installation
Professional Installation Requirements
- Installation by a qualified network technician is recommended to ensure optimal performance and compliance with network standards.
Applications
- Data centres
- Enterprise networking
- Telecommunications rooms
- Server connections
- High-speed backbone links
- SAN (Storage Area Network) environments
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Supports high-speed data transfer, reducing the need for multiple cables and minimising electronic waste.
- Low power loss helps optimise energy efficiency in network infrastructure.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Repelec LC/LC Duplex OM4 50U 30m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centre, enterprise, and backbone network applications.
