Fibre Patch Lead LC/LC Duplex OM4 50U | 3m Length | High Bandwidth | LSZH Jacket | @Pack by Repelec
The Fibre Patch Lead LC/LC Duplex OM4 50U is designed for high-speed data transmission, featuring a 3m length and OM4 50/125µm multimode fibre for optimal performance. With secure LC to LC duplex connectors and a low insertion loss of ≤0.3dB, it's perfect for data centres, enterprise networking, and telecommunications applications. The LSZH jacket ensures safety by reducing toxic emissions in case of fire.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead LC/LC Duplex OM4 50U | 3m Length | High Bandwidth | LSZH Jacket | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-LCLCOM4-3
Alternatively Known As: OM4 LC to LC Fibre Patch Lead, 3m Duplex Fibre Optic Cable, LC-LC Multimode Patch Cord, OM4 50/125µm Fibre Jumper
Technical Specifications
- Connector Type: LC to LC Duplex
- Fibre Type: OM4 50/125µm Multimode
- Length: 3 metres
- Jacket Material: LSZH (Low Smoke Zero Halogen)
- Bandwidth: Up to 4700 MHz·km
- Insertion Loss: ≤0.3dB
- Return Loss: ≥30dB
- Supports 10/40/100Gbps Ethernet
- Dimensions (H x L x W): 3mm x 3000mm x 3mm
- Weight: 0.1 kg
Key Features
- 3 metre length for flexible installations
- OM4 50/125µm multimode fibre for high bandwidth applications
- LC to LC duplex connectors for secure, low-loss connections
- Low insertion loss and high return loss
- Suitable for 10/40/100Gbps Ethernet applications
- LSZH (Low Smoke Zero Halogen) jacket for enhanced safety
Professional Installation Requirements
- Installation by a qualified network technician is recommended to ensure optimal performance and compliance with network standards.
Applications
- Data centres
- Enterprise networking
- Telecommunications rooms
- Server rooms
- High-speed data transmission environments
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- LSZH jacket reduces toxic emissions in case of fire
- Supports high-speed data transmission, enabling efficient network infrastructure
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Repelec LC/LC Duplex OM4 50U 3m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centres, enterprise networks, and telecommunications applications.
