Fibre Patch Lead LC/LC Duplex OM4 50U | 5m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
The Fibre Patch Lead LC/LC Duplex OM4 50U is designed for high-speed data transmission, supporting up to 100Gbps with its OM4 multimode fibre. Featuring secure LC to LC duplex connectors and a low insertion loss of ≤0.3dB, this 5m patch lead is perfect for data centres, enterprise networks, and telecommunications applications, ensuring reliable connections and optimal performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead LC/LC Duplex OM4 50U | 5m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-LCLCOM4-5
Alternatively Known As: OM4 Fibre Patch Lead, LC to LC Duplex Fibre Cable, 5m Multimode Fibre Optic Patch Cord, OM4 LC-LC Patch Cable
Technical Specifications
- Fibre Type: OM4 multimode
- Connector Type: LC to LC duplex
- Core/Cladding Diameter: 50/125µm
- Jacket Material: LSZH (Low Smoke Zero Halogen)
- Length: 5 metres
- Insertion Loss: ≤0.3dB
- Return Loss: ≥30dB
- Bandwidth: Up to 4700 MHz·km
- Colour: Aqua
- Dimensions (H x L x W): 3mm x 5000mm x 3mm
- Weight: 0.1 kg
Key Features
- OM4 multimode fibre for high-speed data transmission up to 100Gbps
- LC to LC duplex connectors for secure and reliable connections
- Low insertion loss and high return loss for optimal performance
- 5 metre length for flexible installation
- 50/125µm core/cladding diameter
- LSZH (Low Smoke Zero Halogen) jacket for enhanced safety
Professional Installation Requirements
- Installation by a qualified network technician is recommended to ensure optimal performance and compliance with network standards.
Applications
- Data centres: High-speed backbone connections
- Enterprise networks: Server and switch interconnections
- Telecommunications: Fibre optic cabling infrastructure
- Campus networks: High bandwidth links between buildings
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- LSZH jacket reduces toxic emissions in case of fire
- Supports high bandwidth, enabling efficient data transfer and reducing energy consumption per bit
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Repelec LC/LC Duplex OM4 50U 5m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centre, enterprise, and telecommunications applications.
