Fibre Patch Lead LC/SC Duplex OM4 50U | 10m Length | Low Insertion Loss | LSZH Jacket | @Pack by Repelec
The Fibre Patch Lead LC/SC Duplex OM4 50U is designed for high-speed data transmission, featuring a 10m length and low insertion loss for optimal performance. Ideal for data centres and enterprise networking, this multimode fibre cable supports 10/40/100Gbps Ethernet applications, ensuring reliable connectivity in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead LC/SC Duplex OM4 50U | 10m Length | Low Insertion Loss | LSZH Jacket | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-LCSCOM4-10
Alternatively Known As: OM4 fibre patch lead, LC to SC duplex fibre cable, 10m multimode fibre optic patch cord, OM4 50/125 LC-SC cable
Technical Specifications
- Fibre Type: OM4 50/125µm multimode
- Connector Type: LC duplex to SC duplex
- Cable Length: 10 metres
- Jacket Material: LSZH (Low Smoke Zero Halogen)
- Insertion Loss: ≤0.3dB (typical)
- Return Loss: ≥30dB
- Operating Wavelength: 850nm/1300nm
- Bandwidth: ≥4700 MHz·km (at 850nm)
- Supports 10/40/100Gbps Ethernet
- Dimensions (H x L x W): 6mm x 10000mm x 3mm
- Weight: 0.15 kg
Key Features
- 10 metre length for flexible installations
- OM4 50/125µm multimode fibre for high-speed data transmission
- LC to SC duplex connectors for versatile connectivity
- Low insertion loss and high return loss
- LSZH (Low Smoke Zero Halogen) jacket for enhanced safety
- Supports 10/40/100Gbps Ethernet applications
Professional Installation Requirements
- Installation by a qualified network technician is recommended to ensure optimal performance and compliance with safety standards.
Applications
- Data centres
- Enterprise networking
- Telecommunications rooms
- Server rooms
- High-speed LAN and SAN environments
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- LSZH jacket reduces toxic emissions in case of fire
- Enables high-speed data transfer, supporting energy-efficient network infrastructure
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Repelec LC/SC Duplex OM4 50U 10m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centres, enterprise networks, and telecommunications applications.
