Fibre Patch Lead SC/SC Duplex OM4 50U | 0.5m Length | Low Insertion Loss | Aqua LSZH Jacket | @Pack by Repelec
The Fibre Patch Lead SC/SC Duplex OM4 50U is designed for high-speed data transmission, featuring a 0.5m length and low insertion loss for optimal performance. Ideal for data centres and enterprise networking, this patch lead is equipped with an LSZH jacket for enhanced safety, making it perfect for critical telecommunications applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead SC/SC Duplex OM4 50U | 0.5m Length | Low Insertion Loss | Aqua LSZH Jacket | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-SCSCOM4-0
Alternatively Known As: OM4 Fibre Patch Lead, SC to SC Duplex Fibre Cable, 0.5m Multimode Fibre Lead, OM4 SC-SC Patch Cord
Technical Specifications
- Connector Type: SC to SC Duplex
- Fibre Type: OM4 Multimode 50/125µm
- Cable Length: 0.5m
- Jacket Material: LSZH (Low Smoke Zero Halogen)
- Insertion Loss: ≤0.3dB
- Return Loss: ≥30dB
- Operating Temperature: -20°C to +70°C
- Core Diameter: 50µm
- Cladding Diameter: 125µm
- Colour: Aqua
- Dimensions (H x L x W): 5mm x 500mm x 5mm
- Weight: 0.1 kg
Key Features
- OM4 multimode fibre for high-speed data transmission
- SC to SC duplex connectors for secure and reliable connections
- Low insertion loss and high return loss
- 0.5 metre length for short-distance patching
- LSZH (Low Smoke Zero Halogen) jacket for enhanced safety
- 50/125µm core/cladding diameter
Professional Installation Requirements
- Installation should be performed by IT or network professionals to ensure optimal performance and compliance with network standards.
Applications
- Data centres
- Telecommunications rooms
- Enterprise networking
- High-speed LAN and SAN connections
- Server rooms
- Backbone fibre links
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- LSZH jacket reduces toxic emissions in case of fire
- Supports high-speed data transfer, enabling efficient network infrastructure
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Repelec SC/SC Duplex OM4 50U 0.5m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centre, enterprise, and telecommunications applications.
