Fibre Patch Lead SC/SC Duplex OM4 50U | 10m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
The Fibre Patch Lead SC/SC Duplex OM4 50U is designed for high-speed data transmission, featuring a 10m length and low insertion loss for optimal performance. Ideal for data centers and enterprise networking, this patch lead ensures reliable connections with its LSZH jacket, enhancing safety and reducing toxic emissions in case of fire.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead SC/SC Duplex OM4 50U | 10m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-SCSCOM4-10
Alternatively Known As: OM4 Fibre Patch Lead, SC to SC Duplex Fibre Cable, 10m Multimode Fibre Optic Patch Cord, OM4 50/125 SC-SC Duplex Cable
Technical Specifications
- Connector Type: SC to SC Duplex
- Fibre Type: OM4 Multimode 50/125μm
- Length: 10 metres
- Jacket Material: LSZH (Low Smoke Zero Halogen)
- Insertion Loss: ≤0.3dB
- Return Loss: ≥30dB
- Operating Wavelength: 850nm/1300nm
- Bandwidth: ≥4700 MHz·km (at 850nm)
- Colour: Aqua
- Dimensions (H x L x W): 10mm x 10000mm x 10mm
- Weight: 0.15 kg
Key Features
- SC to SC duplex connectors for secure and reliable connections
- OM4 multimode fibre for high bandwidth and extended reach
- 10 metre length for flexible installation
- Low insertion loss and high return loss
- LSZH (Low Smoke Zero Halogen) jacket for enhanced safety
Professional Installation Requirements
- Installation should be performed by IT professionals or qualified network technicians to ensure optimal performance and compliance with network standards.
Applications
- Data centers for high-speed network connections
- Enterprise networking environments
- Telecommunications infrastructure
- Server rooms and IT racks
- Campus and building backbone cabling
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- LSZH jacket reduces toxic emissions in case of fire.
- Supports high-speed data transmission, enabling efficient network infrastructure and reducing energy waste.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Repelec SC/SC Duplex OM4 50U 10m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centers, enterprise networks, and telecommunications applications.
