Fibre Patch Lead SC/SC Duplex OM4 50U | 1m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
The Fibre Patch Lead SC/SC Duplex OM4 50U is designed for high-speed data transmission, featuring a 1m length and low insertion loss for optimal performance. Ideal for data centres and enterprise networking, this patch lead supports up to 100Gbps, ensuring reliable connections in critical applications. With its LSZH jacket, it also enhances safety by reducing toxic emissions in case of fire.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead SC/SC Duplex OM4 50U | 1m Length | Low Insertion Loss | Aqua Color | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-SCSCOM4-1
Alternatively Known As: OM4 fibre patch lead, SC to SC duplex fibre cable, 1m multimode fibre optic patch cord, OM4 50/125 SC-SC cable
Technical Specifications
- Connector Type: SC to SC Duplex
- Fibre Type: OM4 Multi-mode (50/125µm)
- Length: 1 metre
- Jacket: LSZH (Low Smoke Zero Halogen)
- Insertion Loss: ≤0.3dB (typical)
- Return Loss: ≥30dB
- Bandwidth: 4700 MHz·km (at 850nm)
- Maximum Data Rate: Up to 100Gbps
- Colour: Aqua
- Dimensions (H x L x W): 5mm x 1000mm x 5mm
- Weight: 0.1 kg
Key Features
- SC to SC duplex connectors for secure, reliable connections
- OM4 multi-mode fibre for high-speed data transmission up to 100Gbps
- Low insertion loss and high return loss for optimal performance
- 1 metre length for flexible patching in racks and cabinets
- 50/125µm core diameter for compatibility with modern networking equipment
- LSZH (Low Smoke Zero Halogen) jacket for enhanced safety
Professional Installation Requirements
- Installation should be performed by IT professionals or qualified network technicians to ensure optimal performance and compliance with network standards.
Applications
- Data centres
- Telecommunications rooms
- Enterprise networking
- Server connections
- High-speed LAN and SAN environments
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- LSZH jacket reduces toxic emissions in case of fire
- Supports high-speed data transfer, enabling efficient network infrastructure and reducing energy consumption per bit
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Repelec SC/SC Duplex OM4 50U 1m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centre, enterprise, and telecommunications applications.
